The AB 2711P-T7C21D8S is a PanelView Plus 7 Standard operator interface featuring a 6.5-inch color TFT touchscreen with VGA resolution, designed for real-time monitoring and control in industrial automation environments.

Powered by 24V DC and running a Windows CE operating system, this unit includes a single Ethernet port and dual USB interfaces for connectivity and expansion. Its IP66-rated front panel ensures resistance to dust and powerful water jets, making it suitable for harsh industrial settings.

Technical Specifications

Model: 2711PT7C21D8S
Series: PanelView Plus 7 Standard
Display Type: TFT Color Touchscreen
Display Size: 6.5 inches (VGA)
Mounting Type: Panel / Direct Wall Mount
Power Supply: 24V DC
Operating System: Windows CE
Application: Human-Machine Interface for automation control

Electrical Specifications

• Supply Voltage (DC): 24 V
• Voltage Type: DC
• Power Input Method: Terminal block or direct panel supply
• Max Current Draw: As per manufacturer guidelines

Communication & Interfaces

• Industrial Ethernet Ports: 1
• USB Ports: 2
• RS-232 Ports: 0
• Supported Protocols: EtherNet/IP
• Unsupported Protocols: DeviceNet, Modbus, Serial ASCII

Display & User Interface

• Screen Size: 6.5″ (diagonal)
• Display Resolution: VGA
• Display Type: TFT Color
• Colour Depth: 262,144 colours
• Touchscreen Type: Resistive
• Integrated Keypad: No
• Software Interfaces: Yes (via USB/Ethernet)

Mechanical Specifications

• Width (Front Panel): 212 mm
• Height (Front Panel): 170 mm
• Built-In Depth: 56.5 mm
• Mounting Options: Direct/wall mount
• Rail Mounting: Not supported
• Front Panel Protection: IP66

Environmental Specifications

• Operating Temperature: 0°C to +55°C
• Storage Temperature: –20°C to +70°C
• Humidity: 5% to 95% RH (non-condensing)
• Ingress Protection: IP66 (front only)
• Application Environment: Industrial panel installations

Compliance & Certifications

• CE Marked: Yes
• UL / cUL Listed: Yes
• RoHS Compliant: Yes
• Standards: IEC 61010-2, EN 61131-2

Key Features & Benefits

✅ 6.5” VGA Touchscreen. Compact yet clear operator interface.

✅ IP66 Front Panel. Withstands water and dust ingress in tough environments.

✅ 24V DC Operation. Industrial standard power supply support.

✅ EtherNet/IP Enabled. Integrates into modern PLC networks.

✅ Dual USB Ports. Expandable and easy to configure.

✅ Windows CE OS. Lightweight and responsive HMI platform.

📦 Order the Allen Bradley 2711P-T7C21D8S from Drive Outlet Megastore

At Drive Outlet Megastore, we provide unbeatable Allen Bradley 2711P-T7C21D8S prices, giving you advanced HMI control in a rugged, compact package.

Perfect for local or distributed visualisation in manufacturing lines, machines, or automation cells, the 2711P-T7C21D8S delivers intuitive performance with flexible mounting and network-ready features.
