Allen Bradley 1769-IA16 Digital Input Module

The AB 1769-IA16 is a Compact I/O digital input module engineered to interface 120V AC control signals into CompactLogix and MicroLogix 1500 controller systems. It features 16 high-density AC input channels, making it an excellent choice for monitoring a wide range of discrete field devices in industrial environments.

With built-in filtering and a consistent 20 ms signal debounce, the 1769-IA16 ensures reliable state detection in noisy electrical conditions. Its compact form factor allows for seamless integration into tight control enclosures without sacrificing performance or expandability.

Technical Specifications

Manufacturer: Allen Bradley
Series: Compact I/O
Part Number: 1769IA16
Module Type: Digital Input Module
Mounting Type: DIN Rail or Panel Mount
Compatible Platforms: CompactLogix, MicroLogix 1500

Electrical Specifications

Number of Digital Inputs: 16
Input Voltage Type: AC
Rated Input Voltage: 120V AC
Permitted Input Voltage Range: 110…110 V
Input Frequency: 47…63 Hz
Signal Debounce Delay: 20 ms
Input Current per Channel: ~0.115 A nominal
Short Circuit Protection: Not available

Mechanical Specifications

Width: 35 mm
Height: 118 mm
Depth: 87 mm
Connection Type: Plug-in terminal block
Housing Type: Modular plastic
Mounting Orientation: Vertical

Environmental Specifications

Operating Temperature Range: 0°C to +60°C
Storage Temperature Range: -40°C to +85°C
Relative Humidity: 5% to 95% (non-condensing)
IP Rating: IP20 (when installed in enclosure)
Pollution Degree: 2
Vibration Resistance: 5 g @ 10–500 Hz

Compliance & Certifications

Certifications: UL, cULus, CE, Class I Division 2
RoHS Compliance: Yes
Explosion Protection: None for dust/gas zones
Safety Standards: EN 61010-1

Key Features & Benefits

✅ 16-Point AC Input – High-density channel count supports large-scale input monitoring

✅ 120V AC Logic – Direct connection to standard industrial voltage levels

✅ Integrated Debounce Filtering – 20 ms input delay ensures signal stability and noise immunity

✅ Plug-in Terminals – Facilitates fast installation and maintenance

✅ Compact Design – Saves panel space in modular Compact I/O architectures

✅ Ideal for Control Panels – Compatible with both CompactLogix and MicroLogix 1500 systems

📦 Order the Allen Bradley 1769-IA16 from Drive Outlet Megastore

At Drive Outlet Megastore we offer unbeatable Allen Bradley 1769-IA16 prices. Equip your control system with reliable 120V AC input monitoring backed by fast shipping across the UK and Europe.
