Allen Bradley 1783-BMS10CGP Stratix 5700 Managed Switch
The AB 1783-BMS10CGP is a powerful and rugged managed industrial Ethernet switch from the Stratix 5700 series, tailored for demanding control and automation environments. Featuring 8 Fast Ethernet copper ports and 2 combo (copper/SFP) ports, this compact Layer 2+ switch delivers high-performance switching and seamless EtherNet/IP integration.
Designed with Full Stratix Firmware and advanced features such as CIP Sync, NAT, VLANs, and Device Level Ring (DLR), this unit offers exceptional network flexibility. It supports dual DC power input (24/48V nominal, 12–60V range) for redundant operation and is DIN rail mountable for easy installation in industrial cabinets.
Technical Specifications
Model: 1783BMS10CGP
Series: Stratix 5700
Device Type: Managed Industrial Ethernet Switch
Software Version: Full Firmware
Switching Layer: Layer 2+
Application: Real-time control networks, high-availability architectures, EtherNet/IP systems
Port Configuration
- Copper Ports (10/100 Mbps): 8 × RJ45
- Combo Ports (10/100/1000 Mbps): 2 × RJ45/SFP (fiber-capable)
- Total Usable Ports: 10
- SFP Compatibility: 100 Mbps / 1 Gbps industrial-grade SFPs
Electrical Specifications
Power Input Range: 12–60V DC
Nominal Power Supply: 24V or 48V DC
Power Redundancy: Yes (dual power input)
Power Connectors: Dual removable terminal blocks
Power Consumption: Low, based on port utilization and SFP usage
Communication & Protocols
Supported Protocols:
- EtherNet/IP
- CIP Sync (IEEE 1588)
- Device Level Ring (DLR)
- NAT (Network Address Translation)
- SNMP, IGMP Snooping
- STP, RSTP
- VLANs, QoS, Access Control Lists
Configuration Tools:
- Web UI
- Studio 5000 Logix Designer
- Command Line Interface (CLI)
Diagnostics: Port mirroring, traffic stats, alarm notifications
Mechanical Specifications
Width: Approx. 70–100 mm
Height: Compact switch format
Depth: Approx. 120 mm
Mounting: DIN rail
Enclosure Rating: IP20 (for control cabinet use)
Weight: Light industrial duty
Environmental Specifications
Operating Temperature: 0°C to 60°C
Storage Temperature: –40°C to +85°C
Humidity: 5% to 95% RH (non-condensing)
Installation Altitude: Up to 2000 m
IP Rating: IP20
Shock & Vibration Resistance: IEC 60068-2 compliant
Compliance & Certifications
CE Marked: Yes
UL / cUL Listed: Yes
RoHS Compliant: Yes
Standards: IEEE 802.3, 802.1D/Q/W, EN 61131-2
Cybersecurity Features: Port lockdown, password access, ACLs
Key Features & Benefits
✅ 10-Port Flexibility: 8 copper + 2 combo ports support copper or fiber
✅ Full Firmware Features: Includes CIP Sync, NAT, DLR, VLANs, QoS
✅ Dual DC Power Inputs: 12–60V range for high-availability installations
✅ Seamless Studio 5000 Integration: Reduces setup and programming time
✅ Compact DIN Rail Design: Optimized for tight industrial enclosures
📦 Order the Allen Bradley 1783-BMS10CGP from Drive Outlet Megastore
At Drive Outlet Megastore, we offer unbeatable Allen Bradley 1783-BMS10CGP prices. Designed for critical industrial Ethernet networks, this Stratix 5700 managed switch is the smart choice for performance, precision, and protection in your automation system.
Check stock now or request a quote
Smarter switching. Smarter plants. Connected by Stratix — Drive Outlet Megastore
