Allen Bradley 2198-P141 Kinetix 5700 DC Bus Supply

The AB 2198-P141 is a DC bus power supply module from the Kinetix 5700 series, delivering up to 47 A continuous output current at a nominal power rating of 31 kW. Designed to power Kinetix 5700 multi-axis servo systems, it accepts a 3-phase 380–480V AC input and outputs DC bus power for distribution to inverter modules.

With an 85 mm compact footprint, this unit includes a dynamic brake chopper and resistor, supports EtherNet/IP network integration, and offers built-in diagnostics to ensure system protection and high reliability for coordinated motion control architectures.

Technical Specifications

Model: 2198P141
Series: Kinetix 5700
Device Type: DC Bus Power Supply
Input Voltage: 3PH, 380–480 VAC
Output Power: 31 kW
Output Current (Nominal): 46.9 A
Form Factor: 85 mm wide
Mounting Type: Panel mount
Application: High-performance servo systems, robotics, packaging, material handling

Electrical Specifications

• Input Voltage Range: 380–480 VAC, 3-phase
• Input Frequency: 50/60 Hz
• Output Type: DC bus
• Output Current: 47 A
• Brake Chopper: Included
• Brake Resistor: Included
• Voltage Type: AC input / DC output
• Bus Sharing: Supports multiple inverter modules via DC link

I/O & Communication Interfaces

• Digital Inputs: 2
• Digital Outputs: 0
• Analog Inputs/Outputs: Not supported
• EtherNet/IP Ports: 2
• RS-485 / USB / Serial: Not supported
• Supported Protocols: EtherNet/IP
• Unsupported Protocols: DeviceNet, SERCOS, MODBUS, TCP/IP, Data Highway

Mechanical Specifications

• Width: 85 mm
• Height: Approx. 380 mm
• Depth: Approx. 200 mm
• Mounting: Panel / rail-mountable (side-by-side with Kinetix 5700 modules)
• Cooling Method: Forced air (fan)
• Enclosure Type: IP20
• Weight: Approx. 3.5 kg

Environmental Specifications

• Operating Temperature: 0°C to +50°C (with derating above 40°C)
• Storage Temperature: –40°C to +85°C
• Humidity: 5% to 95% RH (non-condensing)
• Altitude: Up to 1,000 m without derating
• Shock / Vibration: IEC 60068-2 compliant

Compliance & Certifications

• CE Marked: Yes
• UL / cUL Listed: Yes
• RoHS Compliant: Yes
• EMC Standards: EN 61800-3
• Safety Standards: IEC/EN 61800-5-1

Key Features & Benefits

✅ 31 kW Power Output. High-capacity DC bus supply for multi-axis drive systems.

✅ Integrated Braking. Includes chopper and resistor for energy dissipation.

✅ Compact 85 mm Width. Saves panel space and enables dense system layouts.

✅ EtherNet/IP Support. Network-ready for Logix integration and diagnostics.

✅ Seamless System Integration. Designed to power multiple Kinetix 5700 inverters.
