Allen Bradley 22-COMM-E PowerFlex 40 Communication Module

The AB 22-COMM-E is an EtherNet/IP communication module designed for seamless network integration of PowerFlex 4-class drives. It enables these drives to communicate over EtherNet/IP networks, supporting real-time control and advanced data exchange within Allen Bradley Logix-based architectures.

Compact and DIN-rail or panel-mountable, the 22-COMM-E installs directly into the drive’s communication interface port and allows centralized control, diagnostics, and configuration via RSLogix 5000 or Studio 5000 software platforms. It is a reliable, cost-effective solution for upgrading legacy drives with modern Ethernet-based networking capability.

Technical Specifications

Model: 22COMME
Type: EtherNet/IP Communication Adapter
Compatible Drives: PowerFlex 4, 40, 400 Series
Protocol Support: EtherNet/IP
Interface: RJ-45 Ethernet Port
Mounting Method: Panel or DIN Rail Mountable
Configuration: RSLogix 5000 / Studio 5000
LED Status Indicators: Network and Module Status
Typical Use: Network integration for drive control and diagnostics
Application: Factory automation, drive systems integration, OEM equipment

Electrical & Interface Specifications

Communication Protocol: EtherNet/IP
Network Speed: 10/100 Mbps
Connector Type: RJ-45
Drive Port Connection: Internal communication port
Input Voltage: Supplied via drive (no external power required)
Isolation: Optical and galvanic isolation between drive and network
Network Cable Type: Category 5e or better, unshielded/shielded twisted pair

Mechanical Specifications

Width: Compact form factor
Height: Low-profile module
Depth: Slimline enclosure
Mounting Type: Direct to drive / DIN rail (with mounting bracket)
Housing: Industrial-grade plastic
Weight: < 0.2 kg

Environmental Specifications

Operating Temperature: 0…50 °C
Storage Temperature: -40…85 °C
Humidity: 5–95% non-condensing
IP Rating: IP20 (when installed)
Installation Location: Inside control cabinet
Certifications: CE, cULus, RoHS

Compliance & Communication

EtherNet/IP Supported: Yes
TCP/IP Support: Yes
CIP Messaging Support: Yes
Explicit Messaging: Yes
DPI (Drive Peripheral Interface) Compliant: Yes
Drive Parameter Access: Remote read/write capable
Studio 5000 / Logix Integration: Yes
Other Protocols Supported: No

Key Features & Benefits

✅ Seamless Network Integration – Connect PowerFlex 4-class drives to EtherNet/IP networks

✅ Centralized Drive Control – Enables real-time parameter access and configuration via Studio 5000

✅ Compact Installation – Direct-mount design fits cleanly within control panels

✅ Diagnostics Enabled – Supports drive status monitoring and fault reporting over Ethernet

✅ Low Cost, High Impact – Simple way to upgrade legacy drives with modern communication

✅ No External Power Required – Draws power directly from host drive for clean installs

📦 Order the Allen Bradley 22-COMM-E from Drive Outlet Megastore

At Drive Outlet Megastore we offer unbeatable Allen Bradley 22-COMM-E prices. With 3 units in stock and ready to ship, we ensure fast delivery and expert support to help you network your PowerFlex drives with confidence.
