Danfoss 131B0476 Inverter Drive – 5.5kW, IP20

The Danfoss VLT® AutomationDrive FC 302 (131B0476) is engineered for precision motor control in industrial automation, manufacturing, and variable-speed applications. With its 5.5 kW (7.5 HP) power capacity, PROFIBUS DP MCA 101 communication, and graphical local control panel, this drive ensures efficient motor control, seamless networking, and reliable operation.

Technical Specifications

Model: 131B0476 (FC-302P5K5T5E20H1BGXXXXSXXXXA0BXCXXXXD0)
Type: High-Performance AC Drive for Industrial Automation

Power & Performance

• Power Rating: 5.5 kW / 7.5 HP
• Phase: Three-phase
• Mains Voltage: 380 – 500 VAC
• RFI Filter: H1, RFI Class A1/B (C1)

Build & Design

• Enclosure Type: E20, IP20 / Chassis
• Frame Size: A3
• Coating PCB: Not Coated
• Brake Chopper: Included
• Local Control Panel (LCP): Graphical

Physical Specifications

• Gross Weight: 7.24 kg
• Net Weight: 6.71 kg
• Volume: 27.246 L
• Dimensions (H x W x D): 268 mm x 130 mm x 205 mm
• EAN: 5702427147140

Performance & Efficiency

• Power (160% High Overload – HO): 5.5 kW
• kVA: 9.01
• Power Loss (HO Mode): 187 W

Electrical Ratings

• Continuous Current (HO): 13 A
• Intermittent Current (HO): 20.8 A
• Continuous Current (HO): 11 A
• Intermittent Current (HO): 17.6 A

Additional Options & Features

• Mains Option: No Mains Option
• Software Release: Latest Standard Software (SXXX)
• Software Language Pack: Standard Language Pack
• Communication Option (A): PROFIBUS DP MCA 101
• Standard Cable Entries: Included
• Backup Power Option (D): MCB-107 24V DC backup

Compliance & Standards

• ECCN EU: Y901
• ECCN US: 3A999.a

Key Features & Benefits:

✅ Optimized for Industrial Applications: ideal for motors, conveyors, pumps, and automation systems.

✅ Energy-Efficient Performance: advanced motor control reduces power consumption.

✅ Compact & Reliable Design: space-saving IP20 chassis for easy integration.

✅ Seamless Communication: supports PROFIBUS DP MCA 101 for industrial networking.

✅ Durable & Robust: built with high-quality components for long-term reliability.
