Danfoss 131N9995 Inverter Drive – 0.75kW, IP20

The VLT® AutomationDrive FC 302 (131N9995) is an industry-leading solution for motor control and automation, offering high efficiency, network flexibility, and reliable power backup. With its integrated PROFINET support, compact footprint, and robust IP20 design, this drive is ideal for industrial applications requiring precise speed control and uninterrupted operation.

Technical Specifications

Model: 131N9995 (FC-302PK75T5E20H1XXXXXXSXXXXALBXCXXXXD0)
Type: High-Efficiency Industrial Drive for Automation & Motor Control

Power & Performance

• Power Rating: 0.75 kW / 1.0 HP
• Phase: Three-phase
• Mains Voltage: 380 – 500 VAC
• RFI Filter: H1, RFI Class A1/B (C1)

Build & Design

• Enclosure Type: IP20 / Chassis (E20)
• Frame Size: A2
• Coating PCB: Not Coated PCB
• Brake Chopper: No Brake Chopper
• Local Control Panel (LCP): No LCP
• Control Card: PROFINET MCA 120

Physical Specifications

• Gross Weight: 5.02 kg
• Net Weight: 4.5 kg
• Volume: 21.569 L
• Dimensions:
  • Height: 268 mm
  • Width (no C options): 90 mm
  • Width (with two C options): 150 mm
  • Depth: 205 mm
  • Depth with Option A/B: 220 mm
• EAN: 5702427910195

Additional Options & Features

• Mains Option: No Mains Option
• Software Release: Latest Standard Software (SXXX)
• Standard Cable Entries: Included
• A Option: PROFINET MCA 120 (AL)
• B Option: No B Option (BX)
• D Option: MCB-107 24V DC Backup (D0)

Compliance & Standards

• ECCN EU: Y901
• ECCN US: 3A999.a

Key Features & Benefits:

✅ Optimized Motor Control: Provides precise speed and torque control for automation applications.

✅ PROFINET MCA 120 Integrated: Enables seamless industrial network connectivity.

✅ 24V DC Backup (MCB-107): Ensures system reliability in case of power interruptions.

✅ Compact & Efficient Design: IP20 chassis for easy installation in control panels.

✅ Energy-Efficient Operation: Reduces power loss and ensures cost-effective performance.
