Danfoss 136N8939 Inverter Drive – 18.5kW, IP20

The Danfoss FC 51 (136N8939) is a heavy-duty three-phase variable frequency drive engineered for high-performance control of 18.5kW motors in industrial automation and HVAC systems. With a rugged IP20 chassis, integrated brake chopper, and coated PCB, this VLT® Micro Drive provides powerful, compact, and reliable performance for large-scale motor applications.

Technical Specifications

Model: 136N8939 (FC-051P18KT4E20HXBXCXXXSXXX)
Type: VLT® Micro Drive – Compact Frequency Converter

Power & Performance

• Power Rating: 18.5 kW / 25 HP
• Phase: Three-phase
• Mains Voltage: 380 – 480 VAC
• Frequency: 50/60 Hz
• Frame Size: M5

Build & Design

• Enclosure Type: IP20 / Chassis
• RFI Filter: Not included
• Brake Chopper: Included
• Control Panel: Not included (LCP ordered separately)
• Coating PCB: Coated for enhanced durability
• Dimensions: M5-frame, designed for high-capacity motor control
• Weight:
  • Gross: 9.8 kg
  • Net: 9.5 kg
• EAN: 5710108968502

Control & Features

• Software Release: Standard latest version (SXXX)
• Display Panel: Optional graphical LCP (sold separately)
• Mains Option: No additional mains features
• Adaptation Options: Standard cable entries, no additional adaptations

Compliance & Standards

• ECCN EU: Y901
• ECCN US: 3A999.a

Key Features & Benefits:

✅ Heavy-Duty 18.5kW Output: Built for large industrial motors.

✅ Brake Chopper Integrated: Ideal for deceleration-intensive applications.

✅ Environment-Protected PCB: Coated to resist dust and moisture.

✅ IP20 Chassis: Space-saving design fits standard control enclosures.

📦 Available for Purchase – Order Now!

We offer the most competitive Danfoss 136N8939 prices in Britain.

Contact Drive Outlet Megastore for pricing, stock availability, and expert recommendations.

Our team is ready to help you choose the best VFD solution for your application.
