Keyence SR-2000 1D/2D Code Reader

The SR-2000 is a powerful full-range barcode reader, designed for high-accuracy scanning of 1D and 2D codes over an extended distance. With a high-resolution CMOS sensor, auto-focus technology, and a wide scanning range of up to 2 meters, this unit ensures seamless operation in high-speed industrial applications.

Technical Specifications

Model: SR2000
Type: Full-Range Model

Optical & Imaging Specifications

Receiver Sensor: CMOS Image Sensor
Number of Pixels: 2048 × 1536

Focus: Auto ¹

Light Emitter:

• Light Source: High-Intensity Red LED
• Pointer Light Source: High-Intensity Green LED

Reading Specifications

Supported Symbols:

2D Codes:

• QR, MicroQR, DataMatrix (ECC200), GS1 DataMatrix, PDF417, MicroPDF417, GS1 Composite (CC-A, CC-B, CC-C), DotCode

Barcodes:

• CODE39, ITF, 2of5 (Industrial 2of5), COOP 2of5, NW-7 (Codabar), CODE128, GS1-128, GS1 DataBar, CODE93, JAN/EAN/UPC, Trioptic CODE39, CODE39 Full ASCII, Pharmacode, Postal (Japan Postal, IMB)

Minimum Resolution:

• 2D Code: 0.040 mm
• Barcode: 0.082 mm

Reading Distance: 100 to 2000 mm
Field of View for Reading: 263 × 197 mm at 800 mm Distance

I/O Specifications

Control Input:

• Number of Inputs: 2
• Input Type: Bidirectional Voltage Input
• Maximum Rating: 26.4 VDC
• Minimum ON Voltage: 15 VDC
• Maximum OFF Current: 0.2 mA

Control Output:

• Number of Outputs: 3
• Output Type: Photo MOS Relay Output
• Maximum Rating: 30 VDC
• Maximum Load Current:
  • Single Output: 50 mA or Less
  • 3-Output Total: 100 mA or Less
• Leakage Current (OFF State): 0.1 mA or Less
• Residual Voltage (ON State): 1 V or Less

Communication Interfaces

Ethernet:

• Standard: IEEE 802.3-Compliant, 10BASE-T / 100BASE-TX
• Supported Protocols: TCP/IP, SNTP, FTP, BOOTP, EtherNet/IP™, PROFINET, KV STUDIO, MC Protocol, OMRON PLC Link

Serial Communication:

• Standard: RS-232C-Compliant
• Communication Speed: 9600, 19200, 38400, 57600, 115200 bps
• Supported Protocols: No-Protocol, KV STUDIO, MC Protocol, SYSWAY

USB:

• Standard: USB 2.0 Full Speed-Compliant

Power & Electrical Specifications

Power Voltage: 24 VDC ±10%
Current Consumption: Approx. 1,600 mA

Environmental Resistance

Enclosure Rating: IP65

Operating Conditions:

• Ambient Light:
  • Sunlight: 10,000 Lux
  • Incandescent Lamp: 6,000 Lux
  • Fluorescent Lamp: 2,000 Lux
• Ambient Temperature: 0°C to +45°C
• Relative Humidity: 35% to 85% RH (No Condensation)
• Storage Temperature: -10°C to +50°C
• Storage Relative Humidity: 35% to 85% RH (No Condensation)
• Operating Environment: No Dust or Corrosive Gas Present

Durability & Shock Resistance:

• Vibration Resistance: 10 to 55 Hz, Double Amplitude 0.75 mm, 3 Hours in Each of the X, Y, and Z Directions

Material & Construction

Weight: Approx. 300 g

Key Features & Benefits:

✅ Extended Reading Distance: Covers 100 mm to 2000 mm for maximum flexibility.

✅ High-Resolution CMOS Sensor: 2048 × 1536 pixels for sharp and precise code recognition.

✅ Advanced Autofocus Technology: Automatically adjusts focal position for optimal barcode detection.

✅ Industrial-Grade Durability: IP65-rated for use in demanding manufacturing environments.

✅ Seamless Integration: Ethernet, RS-232C, and USB connectivity for easy system integration.
