Keyence SR-710 Ultra-Compact 1D and 2D Code Reader

The Keyence SR-710 is a middle-range barcode and 2D code scanner, designed for high-speed and high-accuracy reading across a variety of applications. With Class 1 laser safety certification, high-intensity LED lighting, and IP65-rated durability, this scanner ensures consistent performance in industrial and logistics environments.

Technical Specifications

• Manufacturer: Keyence
• Product Series: SR Series
• Model: SR710
• Type: Middle-range barcode & 2D code reader

Laser Pointer & Lighting

• Light Source: Visible semiconductor laser (Wavelength: 660 nm)
• Output: 60 µW
• Pulse Duration: 200 µs
• Laser Class: Class 1 Laser Product (IEC60825-1, FDA (CDRH) Part 1040.10)
• Lighting Source: High-intensity red LED

Reading Capabilities

Supported Codes:

• Barcode: CODE39, ITF, 2of5 (Industrial 2of5), COOP 2of5, NW-7 (Codabar), CODE128, GS1-128, GS1 DataBar, CODE93, JAN/EAN/UPC, Trioptic CODE39, CODE39 Full ASCII, Pharmacode
• 2D Code: QR, MicroQR, DataMatrix (ECC200), GS1 DataMatrix, PDF417, Micro PDF417, GS1 Composite (CC-A, CC-B, CC-C)

Minimum Resolution:

• Barcode: 0.127 mm
• 2D Code: 0.19 mm

Reading Distance (Typical Examples):

• Barcode: 45 to 195 mm (Narrow bar width = 0.5 mm)
• 2D Code: 45 to 165 mm (Cell size = 0.5 mm)

Focal Distance: 100 mm
Field of View (at Focal Distance): 70 mm × 45 mm

I/O & Connectivity

Control Input:

• 2 inputs (IN1 and IN2), non-voltage input (contact, solid-state)

Control Output:

• 4 NPN open collector outputs (OUT1 to 4)
• 30 mA or less (24 V or less)
• Residual Voltage: 0.8 V or less, leakage current 0.1 mA or less

RS-232C Communication:

• Transmission Speed: 9600, 19200, 38400, 57600, 115200 bps
• Supported Protocols: No-protocol, MC protocol, SYSWAY, KV STUDIO

USB Connectivity: USB 2.0 Full Speed compliant

Power & Electrical Specifications

Power Voltage: 5 VDC (+5 %, -10 %)
Current Consumption: 630 mA or less

Protection & Environmental Resistance

Enclosure Rating: IP65

Ambient Light Resistance:

• Sunlight: 10,000 lux
• Incandescent Lamp: 6,000 lux
• Fluorescent Lamp: 2,000 lux

Operating Temperature: 0°C to +45°C
Relative Humidity: 35% to 95% RH (No condensation)
Storage Temperature: -10°C to +50°C (No freezing)
Operating Environment: No dust or corrosive gas present
Vibration Resistance: 10 to 55 Hz, Double amplitude 1.5 mm, 3 hours per X, Y, and Z axes

Material & Construction

Weight: Approx. 160 g (including cable)

Included Accessories

• Instruction Manual

Key Features & Benefits:

✅ Wide Code Compatibility: Reads multiple barcode and 2D code formats efficiently.

✅ High-Speed Scanning: Fast and precise reading with a response time of 200 µs.

✅ Compact & Lightweight: Designed for easy integration into various industrial setups.

✅ USB & RS-232C Connectivity: Ensures versatile communication with multiple devices.

✅ Durable & Reliable: IP65 enclosure provides protection against dust and moisture.
