Omron CJ1W-CORT21 Custom CAN Communication Module

The Omron CJ1W-CORT21 is a flexible user-defined CAN communication unit for CJ-series PLCs, enabling custom CAN messaging using 11-bit and 29-bit identifiers. Designed as a CPU bus communication module, it allows seamless integration with a wide range of CAN-based industrial devices in automotive, logistics, or machine-building environments.

With one CAN port and open-frame protocol support, the CORT21 is ideal for implementing tailored CAN communication structures not supported by standard network profiles.

Technical Specifications

Model: CJ1WCORT21
Series: CJ1W
Product Type: User-Defined CAN Interface Unit
Mounting Type: DIN rail (via CJ-series rack)
Weight (Unpacked): 160 g
Dimensions (W × H × D): 31 × 90 × 78.7 mm
Module Type: CPU Bus Unit
Degree of Protection: IP20 (when installed in control cabinet)

Communication & Protocol

• Bus Interface: CJ CPU Bus
• Communication Protocol: CAN (Controller Area Network)
• CAN ID Support:
  • Standard (11-bit)
  • Extended (29-bit)
• Number of Ports: 1 × CAN communication port
• Data Exchange Mode: User-defined frames
• Use Case: Custom CAN messaging (not DeviceNet or predefined protocols)
• Baud Rate: Configurable via CX-Integrator (refer to manual for details)

Mechanical & Installation

• Connection to PLC: Direct CPU Bus Unit slot (CJ1, CJ2M, CJ2H series)
• CAN Connector: Via separate cable/terminal block (not included)
• Installation: Vertical mounting in PLC rack
• Cooling Method: Natural convection
• Power Supply: Supplied via CJ backplane (no external supply needed)

Environmental Conditions

• Operating Temperature: 0 to 55°C
• Storage Temperature: –25 to +70°C
• Relative Humidity: 10% to 90% RH (non-condensing)
• Altitude: Up to 2000 m
• Shock Resistance: Conforms to IEC 60068-2-27
• Vibration Resistance: Conforms to IEC 60068-2-6

Applications

Perfect for:

• Custom CAN communication in machine tools
• Integration with third-party CAN-enabled sensors or actuators
• Automotive testing systems
• Mobile machinery requiring proprietary CAN messaging
• Projects needing open CAN data format (non-DeviceNet)

Key Features & Benefits

✅ User-Defined CAN Messaging: Full flexibility for OEM or custom applications.

✅ 11- & 29-Bit ID Support: Compatible with both standard and extended CAN frames.

✅ CJ-Series Integration: Plug-and-play with CJ1, CJ2M, and CJ2H CPUs.

✅ Reliable Omron Design: Industrial-grade performance with global support.

✅ Compact Form Factor: 31 mm width fits tightly into control panels.

📦 Available from Drive Outlet Megastore

The Omron CJ1W-CORT21 provides total freedom for CAN communication, giving developers the ability to define messages and protocols tailored to their equipment or system.

Need help implementing a custom CAN solution with CJ-series PLCs? Talk to our control systems team today.

Omron flexibility. Drive Outlet support — custom CAN, made simple.
