Omron K8AK-AS1 24VAC/DC Current Monitoring Relay – Single-Phase Over/Under Current 2–500mA AC/DC, 22.5 mm, 1×SPDT

The Omron K8AK-AS1 24VAC/DC is a precision single-phase current monitoring relay designed for detecting over-current and under-current in low-level AC or DC circuits. Ideal for sensitive load and sensor protection, it operates from a 24VAC/DC supply and offers a fine adjustable detection range from 2 mA to 500 mA. The slim 22.5 mm DIN-rail housing and 1×SPDT relay output make it easy to integrate into compact control panels and instrumentation systems.

Featuring front rotary dials, LED status indication, and reliable electromechanical output contacts, the K8AK-AS1 provides accurate current detection and system protection in automation, instrumentation, and process control applications.

Technical Specifications

Model: K8AK-AS1 24VAC/DC Omron
Series: K8AK Current Monitoring Relays
Function: Over-current / Under-current monitoring (single-phase AC/DC)
Setting Range: 2–500 mA (AC/DC)
Output Type: Relay (SPDT)
Supply Voltage: 24VAC/DC (20.4–26.4V)
Installation Type: DIN rail mount
Terminal Type: Screw terminals
Body Colour: Black
Ideal For: Sensors, instrumentation loops, and precision circuit protection

Electrical Specifications

• Supply Voltage: 24VAC/DC (20.4–26.4V)
• Detection Range: 2–500 mA AC/DC
• Output Contacts: 1×SPDT relay
• Power Consumption: Approx. 1.2W
• Response Time: Fast acting for critical monitoring
• External CT: Not required (direct current measurement)

I/O & Control Interface

• Front Controls: Rotary dials for setpoint and range selection
• Status Indication: LED indicator for relay output and power
• Connection Type: Screw terminals for supply and measurement
• Integration: Compatible with standard control wiring systems

Mechanical Specifications

• Width: 22.5 mm
• Mounting: 35 mm DIN rail
• Housing Material: Industrial-grade plastic
• Colour: Black
• Weight: Approx. 120 g

Environmental Specifications

• Operating Temperature: -10°C to +55°C
• Storage Temperature: -25°C to +65°C
• Humidity: 25–85% RH (non-condensing)
• Vibration Resistance: 10–55 Hz, 0.75 mm amplitude
• Degree of Protection: IP20 (panel mounted)
• Application Category: Industrial monitoring and automation control

Compliance & Certifications

• CE Marked: Yes
• UL / cUL Listed: Yes
• TÜV Certified: Yes
• RoHS Compliant: Yes
• Standards: EN 60947-5-1, EN 60255-1

Key Features & Benefits

✅ Ultra-Sensitive Detection. Monitors very low AC/DC currents from 2 mA.

✅ Dual-Mode Protection. Configurable for overcurrent or undercurrent detection.

✅ Compact 22.5mm Design. Ideal for space-limited control panels.

✅ Universal 24V Supply. Operates from AC or DC control voltage.

✅ LED Status Indicator. Provides clear operational and relay status.

✅ Reliable Switching. SPDT relay for alarm or trip circuit activation.

📦 Order the Omron K8AK-AS1 24VAC/DC from Drive Outlet Megastore

At Drive Outlet Megastore, we offer unbeatable Omron K8AK-AS1 24VAC/DC prices — delivering high-precision, compact current monitoring relays designed for dependable low-current protection and automation control.

Check stock now or request a quote.

Monitor precisely. Protect intelligently. Omron engineered — only at Drive Outlet Megastore.
