NB7W-TW01B Omron 7″ WVGA TFT Touchscreen HMI, 800 x 480, Ethernet, USB Host, Black Bezel, IP65 Front

The Omron NB7W-TW01B is a robust 7-inch wide-format HMI touchscreen engineered for seamless operation, vibrant display quality, and flexible communications. With a bright TFT color screen delivering 800 × 480 resolution and a rugged IP65-rated front panel, it’s ideal for real-time monitoring and control in industrial environments.

This unit offers Ethernet, dual USB, RS-232/422/485 serial communication, and intuitive programming through NB-Designer, making it a flexible and cost-effective interface for small to mid-sized automation projects.

Note: This product has been discontinued. Production ended on 2025-03-31.

Technical Specifications

Model: NB7WTW01B
Brand: Omron
Series: NB
Display Type: TFT color touchscreen
Display Size: 7 inches (diagonal)
Display Resolution: 800 × 480 pixels (WVGA)
Display Colors: 65,536 colors
Grayscale Levels: 64
Ports:

• Ethernet: 1
• USB: 2
• RS-232: 2
• RS-422: 1
• RS-485: 1
  Front Panel Protection: IP65 (front)
  Power Supply: 24 V DC
  Frame Color: Black
  Weight (Unpacked): 1000 g

Mechanical Dimensions

• Front Width: 202.0 mm
• Front Height: 148.0 mm
• Panel Cutout (W × H): 191 × 137 mm
• Built-in Depth: 46 mm

Environmental

• Operating Temperature: Not specified
• IP Protection (Front): IP65
• Cooling Method: Passive/Natural convection

Application Areas

Perfect for use in:

• OEM machinery and skid-mounted systems
• Process control and discrete manufacturing
• Packaging and printing lines
• Food, beverage, and material handling

Key Features & Benefits

✅ 7-inch WVGA TFT Screen: Offers crisp, high-resolution visuals for data and graphics.

✅ Multiple Communication Ports: Includes Ethernet, USB host/device, and serial (RS-232/422/485).

✅ Compact Footprint: Panel-friendly cutout size and only 46 mm depth for shallow enclosures.

✅ User-Friendly Configuration: Supports NB-Designer software for intuitive HMI development.

✅ IP65-Rated Front Panel: Ideal for environments with dust, splash, or light washdown requirements.

📦 Available at Drive Outlet Megastore

Though now discontinued, the Omron NB7W-TW01B remains a reliable and widely used HMI for legacy systems.
