Omron NX-TC3406 Temperature Controller

The Omron NX-TC3406 is an advanced 4-loop temperature control unit for NX-series distributed I/O systems, designed to deliver ultra-precise thermal regulation with real-time response and integrated signal isolation. Supporting a wide range of sensor inputs—including thermocouple and Pt100/Pt1000 RTD types—and providing 4 independent PNP digital outputs, this controller is ideal for machine builders and process automation applications that demand tight thermal stability.

Equipped with screwless Push-in Plus terminals for fast wiring and integrated into the NX I/O Bus, the NX-TC3406 ensures seamless EtherCAT-based control and synchronisation in Omron Sysmac environments.

Control & Input Specifications

Model: NX-TC3406
Control Type: Heat or Cool (per loop)
Number of Control Loops: 4
Sensor Inputs:

• Thermocouples: B, C (WRe5-26), E, J, K, L, N, R, S, T, U, P (PLII)
• RTDs: Pt100, Pt1000, JPt100
  Number of Analog Inputs: 4 (thermocouple/PT RTD only)
  Input Isolation: Yes (isolated input circuits)
  Conversion Time: 50 ms per unit
  Signal Processing: Free-running

Output Specifications

• Digital Outputs: 4 × PNP (transistor outputs)
• Output Type: PNP, PWM-capable
• Rated Output Voltage: 24 VDC
• Rated Output Current: 21 mA per point
• Analog Outputs: None

Electrical & Mechanical

• Power Supply Voltage: Supplied via NX I/O Bus
• Mounting Method: DIN rail
• Connection Type: Push-in Plus (screwless clamp)
• Number of Connectors: 2
• Detachable Connector: No
• Unit Dimensions (W × H × D): 24 × 100 × 80 mm
• Weight: 140 g (unpacked)
• Degree of Protection: IP20

Environmental Ratings

• Operating Temperature: 0 to 55°C
• Storage Temperature: –25 to 70°C
• Humidity Range: 10% to 95% RH (non-condensing)
• Altitude Limit: 2,000 m max
• Shock Resistance: Conforms to IEC 60068-2-27
• Vibration Resistance: Conforms to IEC 60068-2-6
• Pollution Degree: 2 (IEC 61010-2-201 compliant)
• EMC Noise Immunity: IEC 61000-4-4, 2 kV (power line)
• Overvoltage Category: II

System Integration

• I/O System Bus: NX I/O Bus
• Compatible Platforms: NX-series, NJ-series, and NY-series controllers (via EtherCAT)
• Software Support: Sysmac Studio
• Heater Burnout Detection: Not supported on this model
• SIL Rating: Not SIL-rated (IEC 61508)

Applications

Ideal for:

• Multi-zone heating systems
• Semiconductor processing equipment
• Packaging machinery with thermal sealing
• Plastics and extrusion machines
• Food and pharmaceutical temperature control

Key Features & Benefits

✅ 4 Independent Loops: Simultaneous multi-zone control in one compact unit.

✅ Wide Sensor Compatibility: Works with most thermocouples and RTD standards.

✅ Fast Wiring: Push-in Plus terminals reduce panel assembly time.

✅ Compact Width: Just 24 mm for space-constrained DIN rail environments.

✅ Omron Sysmac Ready: Fully integrates into NX/NJ/NY-series automation networks.

📦 Available from Drive Outlet Megastore

The Omron NX-TC3406 delivers powerful, flexible, and highly responsive temperature control for EtherCAT-based automation systems. From packaging to high-precision industrial heating, it’s your go-to unit for consistent and compact temperature regulation.

Reach out now for technical consultation and best-in-market pricing.

Smart control. Compact performance. Only at Drive Outlet.
