Schneider BMXCPS3020 Power Supply Module

The Schneider BMXCPS3020 is a high-performance Modicon X80 power supply module, providing 31.2 W of power with a 24–48 V DC isolated input. It features an IP20-rated chassis, making it suitable for panel-mounted industrial automation systems.

Engineered for demanding applications, this module supports both Modicon M340 and M580 programmable automation controllers (PACs). It’s designed for machine builders seeking fast response, robust performance, and seamless integration with Schneider Electric’s Modicon X80 I/O platform.

Technical Specifications

Model: BMXCPS3020
Type: Power Supply Module for Modicon X80

Performance & Capacity

• Primary Voltage:
  • 24V to 48V DC (Isolated)
• Primary Voltage Limits:
  • 18V to 62.4V
• Supply Circuit Type:
  • DC
• Secondary Power Output:
  • 15W at 3.3V DC (I/O Module Logic Power Supply)
  • 31.2W at 24V DC (I/O Module & Processor Power Supply)
• Current at Secondary Voltage:
  • 1.3A at 24V DC (I/O Module & Processor Power Supply)
  • 4.5A at 3.3V DC (I/O Module Logic Power Supply)
• Input Current:
  • 0.83A at 48V
  • 1.65A at 24V
• Inrush Current:
  • 30A at 24V
  • 60A at 48V
• Maximum Power Dissipation:
  • 8.5W
• Protection Types:
  • Internal Fuse (Not Accessible) – Primary Circuit
  • Overload Protection – Secondary Circuit (24V Sensor Power Supply)
  • Overvoltage Protection – Secondary Circuit (24V Sensor Power Supply)
  • Short-Circuit Protection – Secondary Circuit (24V Sensor Power Supply)
• Insulation Resistance:
  • ≥ 10 MΩ (Primary/Ground & Primary/Secondary)
• Dielectric Strength:
  • 1500V Primary/Ground
  • 1500V Primary/Secondary
• Immunity to Microbreaks:
  • 1 ms

Connectivity & Controls

• Electrical Connections:
  • 2-Pin Connector – Alarm Relay
  • 5-Pin Connector – Line Supply, Protective Earth
• Control Type:
  • RESET Push-Button (Cold Restart)
• Local Signaling:
  • 1 LED (Green) – Rack Voltage OK
• Maximum Cable Distance Between Devices:
  • 10m (Power Supply Cable, Copper 1.5mm²)
  • 15m (Power Supply Cable, Copper 2.5mm²)

Power & Environmental Specifications

• MTBF Reliability: 4,600,000 Hours
• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 5% to 95% at 55°C (Non-Condensing)
• Operating Altitude:
  • 0 to 2000 m (Standard Operation)
  • 2000 to 5000 m (With Derating Factor)
• IP Degree of Protection: IP20
• Vibration Resistance: 3 gn
• Shock Resistance: 30 gn
• Protective Treatment: TC

BMXCPS3020 Physical Specifications

• Net Weight: 0.34 kg
• Package 1 Dimensions (H x W x L): 13.18 cm x 15.44 cm x 15.65 cm
• Package 1 Weight: 500 g
• Package 2 Dimensions (H x W x L): 30.00 cm x 40.00 cm x 60.00 cm
• Package 2 Weight: 7.22 kg
• Package 3 Dimensions (H x W x L): 75.00 cm x 60.00 cm x 80.00 cm
• Package 3 Weight: 40.00 kg
• Number of Units in Package 1: 1
• Number of Units in Package 2: 12
• Number of Units in Package 3: 48

Key Features & Benefits:

✅ DC Voltage Compatibility: Operates on 24-48V DC input.

✅ Reliable Power Output: Provides stable 24V DC and 3.3V DC power for I/O modules and processors.

✅ Integrated Protection Features: Overload, overvoltage, and short-circuit protection.

✅ Cold Restart Function: RESET push-button for quick system recovery.

✅ Compact & Modular: Fits seamlessly into Modicon X80 racks.

✅ Industrial-Grade Performance: Designed for high-reliability and long-term operation.
