SICK KTM-WP11172P Contrast Sensor (1082138)

The SICK KTM-WP11172P is a compact, high-speed contrast sensor optimized for detecting print marks and color transitions in packaging and labeling lines. With RGB LED technology, ultra-fast 32 µs response time, and teach-in via static/dynamic modes, it offers precise contrast detection in even the fastest industrial applications.

Technical Specifications

Model: KTM-WP11172P
Part No.: 1082138
Product Type: Contrast Sensor
Application: High-speed print mark detection and contrast transitions on packaging lines

Optical Performance

Sensing Distance: ≤ 12.5 mm
Sensing Distance Tolerance: ± 3 mm
Light Source: RGB LED

Wavelengths:

• Blue: 470 nm
• Green: 525 nm
• Red: 625 nm

Light Spot Size: 1.6 mm × 9.5 mm
Light Emission: From long side of housing
Light Spot Direction: Vertical
Receiving Filters: None

Adjustment Interface: Teach-in button
Teach-in Modes:

• 2-point static
• 2-point dynamic
• Proximity to mark
  Default Teach-in: Static (ET)

Electrical Interface

Supply Voltage: 12 V DC to 24 V DC
Ripple: ≤ 5 Vpp
Current Consumption: < 50 mA

Switching Frequency: 15 kHz
Response Time: 32 µs
Jitter: 15 µs

Output Type: PNP
Output Voltage (PNP): HIGH = UV ≤ 2 V / LOW ≈ 0 V
Output Current (Imax): 50 mA

Teach Input (ET):

• Teach: 10.8 V … < UV
• Run: < 2 V or open

Retention Time (Teach): 28 ms (non-volatile)
Switching Mode: Light/dark switching
Protection Class: III

Circuit Protection:

• Reverse polarity protection
• Short-circuit protection
• Interference suppression

Connection Type: Cable with M12 male connector, 4-pin, 0.2 m

Mechanical Data

Enclosure Rating: IP67
Housing Design: Small rectangular
Housing Material: ABS
Optics Material: PMMA
Display Indicators:

• Green LED: Power
• Yellow LED: Output status
  Dimensions (W x H x D): 12 mm × 31.5 mm × 21 mm
  Weight: Approx. 20 g

Certificates and Compliance

• European Conformity (CE)
• UKCA Compliant
• cULUS Listed
• RCM (Australia/New Zealand)
• RoHS Compliant

Applications

Ideal For:

• Print mark detection in high-speed packaging lines
• Color contrast tracking in label applicators
• Film edge detection and verification
• Detection of marks on glossy or transparent packaging materials

Key Features & Benefits

✅ Ultra-Fast Performance: 15 kHz switching frequency and 32 µs response time for dynamic applications.

✅ RGB LED Detection: Auto-selects optimal color wavelength for best contrast differentiation.

✅ Flexible Teach-In Modes: Supports static, dynamic, and proximity-based teach-in methods.

✅ Compact and Lightweight: Small housing and short cable for tight installations and robotic arms.

✅ Rugged Design: IP67 protection, ABS housing, and reverse polarity/short-circuit protection.
