SICK RT-P1223 Photoelectric Proximity Sensor (1063135)

The SICK RT-P1223 is a high-precision photoelectric proximity sensor with background suppression, designed specifically for ZoneControl applications in material handling and conveyor systems.

Operating on infrared LED light, it offers a reliable sensing range from 60 mm to 900 mm with a focused 7° detection angle, making it ideal for accurately detecting objects without interference from background surfaces. Its robust IP67 housing, fast 2 ms response time, and PNP output ensure stable operation in demanding industrial environments.

Technical Specifications

Model: RT-P1223 SICK
Part Number: 1063135
Product Type: Photoelectric proximity sensor
Functional Principle: Background suppression
Sensing Range: 60 mm to 900 mm
Focus Angle: 7°
Type of Light: Infrared LED
Wavelength: (Not specified – standard for IR)
Light Spot Size (at 500 mm): Ø 20 mm
Adjustment Method: 9-turn Potentiometer
Special Applications: ZoneControl

Mechanical & Electrical Data

Dimensions (W × H × D): 20.6 mm × 99.2 mm × 48.9 mm
Housing Design: Rectangular
Output Type: PNP
Switching Mode: Light switching
Output Current (Max.): ≤ 100 mA
Response Time: 2 ms
Switching Frequency: 250 Hz
Supply Voltage (UB): 10 V DC to 30 V DC
Ripple: < 5 Vpp
Current Consumption: 20 mA
Connection Type: 300 mm cable with M12 male connector, 4-pin
Circuit Protection: A, C, D
Protection Class: III
Enclosure Rating: IP67
Housing Material: Plastic, ABS
Weight: 175 g
Shock & Vibration Resistance: According to IEC 68

Environmental Data

Operating Temperature: –40 °C to +60 °C
Storage Temperature: –40 °C to +75 °C
UL File Number: NRKH.E189383 & NRKH7.E189383

Applications

Ideal For:

• Conveyor ZoneControl systems
• Presence detection on automated material handling lines
• Sensing of varying product sizes without background interference
• Logistics automation and warehouse flow control

Key Features & Benefits

✅ Background Suppression: Accurate detection regardless of background reflections.

✅ Focused Detection: Narrow 7° angle ideal for precise targeting.

✅ Fast Response Time: 2 ms switching for dynamic operations.

✅ IP67 Protection: Withstands harsh industrial conditions.

✅ Infrared LED: Invisible light source ideal for inconspicuous detection.
