Siemens 6ES7134-4GB11-0AB0 Analog Input Module

The Siemens SIMATIC DP ET200S 2AI Module 6ES71344GB110AB0 was designed for high-accuracy analog current measurement, supporting +/-20mA and 4…20mA 4-wire transmitters. With a compact 15 mm width and SF LED fault detection, it ensured robust signal acquisition for ET200S systems.

Technical Specifications

Model: 6ES7134-4GB11-0AB0 Siemens
Type: Electronics Module – 2 Analog Inputs (2AI) for SIMATIC DP ET200S

Power & Performance

• Analog Inputs: 2AI Standard I-4DMU
• Input Range: +/-20mA (13-bit + sign), 4…20mA (12-bit for 4-wire transmitters)
• Cycle Time: 65 ms per channel
• Status Indication: SF LED (Group Fault Detection)

Interfaces & Communication

• System: SIMATIC DP ET200S Series
• Module Width: 15 mm
• Signal Types: Analog Current Input

Physical Specifications

• Net Weight: 0.044 kg
• Packaging Dimensions (W x H x D): 6.50 cm x 9.00 cm x 2.20 cm
• Package Size Unit of Measure: CM
• Quantity Unit: 1 Piece
• Packaging Quantity: 1
• Country of Origin: China

Product Lifecycle & Compliance

• Product Lifecycle (PLM): PM410 – Product Cancellation
• Product Cancellation Date: 01.10.2023
• Export Control Regulations: ECCN: EAR99H / AL: N
• Compliance with RoHS Directive: Since 31.12.2008
• WEEE Take-Back Obligation: Yes
• REACH Art. 33 Candidate Substances:
  • Lead (CAS-No. 7439-92-1 > 0.1% w/w)
  • Lead monoxide (CAS-No. 1317-36-8 > 0.1% w/w)
  • Lead titanium zirconium oxide (CAS-No. 12626-81-2 > 0.1% w/w)
• SCIP Number: 76a4df4d-498f-437b-a1c6-55044eef21a6

Additional Product Information

• EAN: 4025515072430
• UPC: 662643231397
• Commodity Code: 85389091
• Catalog ID: ST76
• Product Group: 4467
• Group Code: R151
• Product Class: A – Standard stock product, returnable within guidelines

Key Features & Benefits:

✅ 2 Analog Inputs (AI): Supports +/-20mA and 4…20mA signals.

✅ High Accuracy Conversion: 13-bit + sign or 12-bit resolution.

✅ Compact 15 mm Width: Saves space in control cabinets.

✅ Fault Monitoring: Group fault detection with SF LED.

✅ Built to Siemens Standards: Reliable operation in industrial environments.
