Siemens 6ES7151-3BA23-0AB0 SIMATIC DP Interface Module

The Siemens 6ES7-151-3BA23-0AB0 Interface Module delivers high-performance communication via PROFINET, supporting extensive I/O modules within the ET 200S architecture. A perfect spare part for maintaining or restoring existing installations.

Technical Specifications

Model: 6ES7151-3BA23-0AB0 Siemens
Series: SIMATIC DP
Module Type: Interface Module (IM 151-3 PN HF)
Transmission Rate: 100 Mbit/s
Bus Connection: 2× RJ45 (with termination module included)
Max Expansion: Supports up to 63 I/O modules
Module Width Support: Up to 2 meters total width
Mounting: For ET 200S distributed I/O
Lifecycle Status: Cancelled (Spare Part Only)
Cancellation Date: 01.10.2023

Function & Application

• Purpose: Interface module enabling high-performance PROFINET communication for ET 200S distributed I/O systems.
• Typical Applications:
  • Connection of remote I/O racks via PROFINET
  • Distributed control in modular automation systems
  • Use in machine building and process control environments
  • Ideal for systems using ET 200S architecture requiring spare part replacements

Performance & Features

• High-Speed Transmission. 100 Mbit/s PROFINET capability.
• Supports 63 Modules. Accommodates extensive I/O configurations.
• RJ45 Dual Ports. For flexible daisy-chaining or line topology.
• Compact Design. Space-saving for control cabinet applications.
• Reliable Connectivity. Termination module included for plug-and-play installation.

Delivery & Compliance

• Packaging Dimensions: 8.30 × 12.80 × 7.30 cm
• Net Weight: 0.200 kg
• Packaging Quantity: 1 Piece
• Country of Origin: Germany
• Estimated Dispatch Time: 1 Working Day

Product Compliance & Classification

• RoHS Compliance: Since 25.11.2009
• WEEE Take-Back Obligation: Yes
• SCIP Number: 77655740-aa75-4b76-ae64-3ef0c1f58187
• REACH Substances:
  • Lead (CAS 7439-92-1) > 0.1%
  • Lead monoxide (CAS 1317-36-8) > 0.1%
  • 2-methyl-1-(4-methylpentyl)-2-propyl-1,3-dioxolane (CAS 71868-10-5) > 0.1%
  • Bisphenol A (CAS 80-05-7) > 0.1%
• Commodity Code: 85176200
• Catalog ID: ST76
• Product Group: 4467
• Group Code: R151
• Product Class: A – Stock item, returnable
• EAN: 4025515076131
• UPC: 662643400892

Key Features & Benefits:

✅ 100 Mbit/s PROFINET Interface. Fast, reliable data transfer.

✅ Supports 63 I/O Modules. Ideal for larger distributed systems.

✅ RJ45 Bus Connection. Dual-port interface with included terminator.

✅ Compact for ET 200S. Optimized for control panel space.

✅ Ready-to-Install. Ships with termination module.
