Siemens 6ES7231-5QF32-0XB0 Analog Input Module

The Siemens SM 1231 TC Analog Input Module (6ES7-231-5QF32-0XB0) provides 8 analog inputs for thermocouple sensors, delivering high-resolution temperature data across a variety of process environments. Engineered for use with the SIMATIC S7-1200 PLC, this module enables precision monitoring in ovens, furnaces, and industrial HVAC systems—all easily configurable via the TIA Portal.

Technical Specifications

Model: 6ES7231-5QF32-0XB0 Siemens
Type: SIMATIC S7-1200 SM 1231 TC Analog Input Module – 8x AI Thermocouples

Power & Performance

• Analog Inputs: 8x AI for thermocouples
• Supported Sensor Types: Multiple thermocouple types (Type J, K, T, E, N, S, R, etc.)
• Resolution: High-resolution measurement for precision temperature inputs
• Sampling Time: Fast update cycles for responsive data logging
• Signal Range: Varies based on thermocouple type
• Isolation: Channels electrically isolated from the controller

Interfaces & Communication

• System Integration: Designed for SIMATIC S7-1200 PLC systems
• Configuration Software: TIA Portal (STEP 7 Basic/Professional)
• Application Use: Industrial process control, temperature monitoring, heating & cooling systems

Physical Specifications

• Net Weight: 0.191 kg
• Packaging Dimensions (W x H x D): 9.00 cm x 10.70 cm x 5.80 cm
• Package Size Unit of Measure: CM
• Quantity Unit: 1 Piece
• Packaging Quantity: 1
• Country of Origin: China

Product Lifecycle & Compliance

• Product Lifecycle (PLM): PM300 – Active Product
• Export Control Regulations: ECCN: 9N9999 / AL: N
• Compliance with RoHS Directive: Since 30.08.2013
• WEEE Take-Back Obligation: Yes

REACH Art. 33 Candidate Substances:

• Lead (CAS-No. 7439-92-1 > 0.1% w/w)
• Lead monoxide (CAS-No. 1317-36-8 > 0.1% w/w)
• 4,4′-isopropylidenediphenol (CAS-No. 80-05-7 > 0.1% w/w)
• SCIP Number: dea248d1-0af7-43d3-ae25-e8c330decbd7

Additional Product Information

• EAN: 6940408101906
• UPC: 887621424732
• Commodity Code: 85389091
• Catalog ID: ST72
• Product Group: 4508
• Group Code: R132
• Product Class: A – Standard stock product, returnable within guidelines

Key Features & Benefits:

✅ Supports Multiple Thermocouple Types: J, K, T, E, N, S, R, and more.

✅ High-Resolution Measurement: Ensures accuracy in critical temperature zones.

✅ Compact Design: Ideal for panel-mounted S7-1200 automation systems.

✅ Plug-and-Play Configuration: Fully integrated into TIA Portal.

✅ Industrial-Grade Build: Suitable for harsh and demanding applications.
