Allen Bradley 1440-SDM02-01RA PowerMonitor 5000 Module – 4 Voltage & 4 Current Channels, EtherNet/IP, Advanced Power & Energy Analysis

The Allen Bradley 1440-SDM02-01RA is a high-performance PowerMonitor 5000 module designed for precision monitoring of electrical power systems in industrial automation environments. It provides dynamic power quality measurement with 4 voltage and 4 current input channels, sampling 1024 data points per channel every 12–17 ms, enabling real-time, cycle-by-cycle analytics for diagnostics, efficiency optimization, energy cost reduction, and asset protection.

With EtherNet/IP connectivity, digital & analog I/O, and advanced processing capable of calculating over 6,000 parameters per electrical cycle, the 1440-SDM02-01RA is ideal for ControlLogix system integration, SCADA reporting, load profiling, harmonics analysis, and power quality monitoring in critical electrical distribution systems.

Technical Specifications

Model: 1440-SDM02-01RA Allen Bradley
Series: 1440 Power & Energy Monitoring
Module Type: Dynamic Power Monitoring I/O Module
Input Channels: 4 × Voltage, 4 × Current
Output Types: Digital & Analog Outputs
Communication Port: Native EtherNet/IP
For Use With: ControlLogix & FactoryTalk SCADA Systems
Dimensions: 94 × 97 × 94 mm

Electrical & Performance Details

• Dynamic Sampling: 1024 data points per channel, per electrical cycle
• Cycle Processing Speed: Every 12–17 ms
• Calculated Parameters: Over 6,000 per cycle
• Digital Inputs: 4 × for WAGES (Water, Air, Gas, Electric, Steam) data collection
• Digital/Analog Outputs: 4 × outputs for SCADA/control interface
• Alarm Capability: Configurable up to 20 event alarms
• Virtual Wiring Correction: Supported

Model Variants (PowerMonitor 5000 Series)

• M5 (Base Model): Core power & energy measurement
• M6: Includes M5 features + Harmonics + Oscillography + Event Sync
• M8: Includes M6 features + Flicker + Interharmonics + Transient Detection

Mechanical Specifications

• Mounting: Control cabinet / panel installation
• Connection Type: Standard terminal connections
• Form Factor: Industrial-grade compact chassis

Environmental & Application Use

• Operating Environment: Industrial electrical distribution and automation networks
• Typical Use Cases: Power quality monitoring, load profiling, harmonics detection, energy cost analysis, SCADA data integration
• Industry Applications: Manufacturing, utilities, data centers, heavy process plants

Compliance & Certifications

• CE Marked: Yes
• UL / cUL Listed: Yes
• RoHS Compliant: Yes

Key Features & Benefits

✅ Advanced real-time power monitoring across 8 input channels.

✅ Native EtherNet/IP ensures seamless integration with ControlLogix and FactoryTalk.

✅ Over 6,000 power parameters calculated per cycle for deep diagnostics & analysis.

✅ Oscillography and harmonics detection enable predictive maintenance and fault investigation.

✅ WAGES input support for comprehensive utility consumption tracking.

✅ Configurable alarms allow proactive protection against abnormal conditions.

📦 Order the Allen Bradley 1440-SDM02-01RA from Drive Outlet Megastore

At Drive Outlet Megastore we offer unbeatable Allen Bradley 1440-SDM02-01RA prices, with fast delivery and full support for ControlLogix and PowerMonitor 5000 integration.

Check stock now or request a quote.

Control with confidence. Allen Bradley engineered — only at Drive Outlet Megastore.
