Allen Bradley 1762-OW16 Digital Output Module

The AB 1762-OW16 is a 16-point digital relay output module for MicroLogix 1200 systems, offering robust and flexible switching for both AC and DC loads. Designed for general-purpose control, this module supports voltages from 10V to 230V and provides a total output current capacity of 16 A, making it suitable for controlling solenoids, lamps, contactors, and other discrete devices.

The 1762-OW16 uses mechanical relay contacts to isolate outputs from the control logic, ensuring reliable operation in electrically noisy environments. Its compact, DIN-rail-mountable form factor integrates seamlessly into MicroLogix expansion slots.

Technical Specifications

Model: 1762OW16
Series: MicroLogix 1200
Type: Digital Relay Output Module
Number of Outputs: 16 (mechanical relay)
Output Type: AC/DC Relay Contact
Mounting Style: DIN rail (MicroLogix expansion)
Application: Discrete output control, solenoids, relays, lights, alarms

Electrical Specifications

Permitted Output Voltage: 10V to 230V (AC/DC)
Max Output Current: 16 A total (channel rating varies)
Output Type: Form A relay (SPST-NO)
Short-Circuit Protection: Not included
Switching Frequency: Low (mechanical relay rated)
Isolation: Relay isolated per point

Communication & Integration

Controller Compatibility: MicroLogix 1200
Configuration: Auto-detect via controller firmware
Terminal Connection: Screw terminal block (removable)
Logic Interface: TTL compatible

Mechanical Specifications

Width: 40.4 mm
Height: 90 mm
Depth: 87 mm
Mounting Type: DIN rail
Plug Connection Type: Screw terminals

Environmental Specifications

Operating Temperature: 0°C to 55°C
Storage Temperature: –40°C to +85°C
Humidity: 5% to 95% RH, non-condensing
IP Rating: IP20 (cabinet installation required)
Pollution Degree: 2

Compliance & Certifications

CE Marked: Yes
UL / cUL Listed: Yes
RoHS Compliant: Yes
Standards: IEC 61131-2, EN 61010-2-201

Key Features & Benefits

✅ 16 Relay Outputs: High-capacity control for both AC and DC devices

✅ Wide Voltage Range: Handles loads from 10V up to 230V

✅ Electrically Isolated Channels: Protects control logic from field interference

✅ Reliable Mechanical Relays: Time-tested switching for general-purpose automation

✅ Compact Footprint: Fits directly into MicroLogix 1200 expansion chassis
