Allen Bradley 1769-IR6 RTD/Resistance Input Module – Compact I/O, 6-Channel RTD Input, 0–300Ω Measurement Range

The Allen Bradley 1769-IR6 is a 6-channel RTD/resistance input module for CompactLogix and MicroLogix 1500 systems, designed specifically for high-accuracy temperature measurement. Supporting a wide variety of RTD sensor types and resistance inputs up to 300 ohms, the module offers reliable and stable temperature monitoring in industrial automation environments.

The 1769-IR6 provides six independent RTD channels, each with screw-type terminals for secure wiring, and is ideal for applications requiring precise thermal measurement such as heating systems, ovens, process control, and HVAC automation. With a compact modular design, it integrates directly into the Compact I/O chassis while maintaining ease of installation and diagnostics.

Technical Specifications

Model: 1769-IR6
Brand: Allen Bradley
Series: Compact I/O
Product Type: RTD / Resistance Input Module
Number of Inputs: 6 independent RTD channels
Supported Inputs: RTD & resistance (0–300Ω)
Input Type (Supported): Resistance thermometer (RTD)
Input Types (Not Supported): Current, voltage, resistor, thermocouple
Analog Outputs: 0
Connection Type: Screw terminal connection
Dimensions (W × H × D): 87 × 118 × 35 mm
Explosion Safety (Gas): None
Explosion Safety (Dust): None

Electrical & Performance Details

• RTD Inputs: 6 channels
• Resistance Range: 0–300Ω
• Input Signal Type: RTD (Pt100, Ni100, etc.)
• Temperature Measurement: High-accuracy thermal monitoring
• Input Isolation: Channel-to-system isolation for noise reduction
• Analog Outputs: None (input-only module)

Mechanical Specifications

• Width: 87 mm
• Height: 118 mm
• Depth: 35 mm
• Mounting: Compact I/O chassis slot
• Housing: Compact modular industrial enclosure
• Connections: Screw-type terminal block

Environmental & Application Suitability

• Typical Applications: Temperature control, oven monitoring, HVAC, thermal profiling, industrial process control
• Supported Sensors: RTDs requiring 0–300Ω measurement range
• Suitable For: Any application where stable, accurate thermal measurement is essential
• Installation Environment: Industrial control panels and automation cabinets
• Explosion Safety: Not ATEX/IECEx rated (non-hazardous environments)

Compliance & Certifications

• UL / cUL Listed: Yes
• CE Marked: Yes
• RoHS Compliant: Yes
• NEMA / IEC Standards: Industrial control certified

Key Features & Benefits

✅ Six RTD input channels for multi-point temperature measurement.

✅ 0–300Ω resistance range compatible with common industrial RTDs.

✅ High-accuracy input processing for stable and reliable temperature readings.

✅ Compact I/O design integrates seamlessly with CompactLogix systems.

✅ Screw terminal connections ensure secure field wiring.

✅ Ideal for ovens, HVAC and process control requiring precise thermal monitoring.

✅ Non-hazardous area compliant for standard industrial environments.

📦 Order the Allen Bradley 1769-IR6 from Drive Outlet Megastore

At Drive Outlet Megastore we offer unbeatable Allen Bradley 1769-IR6 prices, with fast UK & EU delivery and expert support for Compact I/O and temperature measurement applications.

Check stock now or request a quote.

Achieve precise and reliable temperature monitoring with the Allen Bradley 1769-IR6 — engineered for RTD accuracy and industrial performance, available now from Drive Outlet Megastore.
