Allen Bradley 2085-OF4 Analogue Output Module

The AB 2085-OF4 is a compact and reliable analog output module from the Micro800 series, designed for applications requiring precise voltage or current output. It features four analog output channels, configurable for ±10V bipolar voltage or 0–20 mA current signals, making it ideal for process control, instrumentation, and motion feedback systems.

This module is optimized for seamless integration with Micro820, Micro850, and Micro870 controllers, enabling flexible I/O expansion in distributed or compact control environments.

Technical Specifications

Model: 2085OF4
Series: Micro800
Module Type: Analog Output
Number of Outputs: 4
Signal Type: Voltage (±10V), Current (0–20 mA)
Resolution: 12-bit
Isolation: Non-isolated
Mounting Type: Plug-in to controller or I/O base

Electrical Specifications

Output Voltage Range: ±10 V (Bipolar)
Output Current Range: 0–20 mA
Output Load Impedance:

• Voltage: ≥1 kΩ
• Current: ≤500 Ω
  Power Supply: Provided by base controller

Mechanical Specifications

Mounting Method: DIN Rail (via base controller)
Plug Connection: Plug-in (to Micro800 base)
Width: 90 mm
Height: 28 mm
Depth: 87 mm
Weight: Approx. 150 g
Enclosure Type: Open type (IP20)

Environmental Specifications

Operating Temperature: 0°C to +55°C
Storage Temperature: -40°C to +85°C
Relative Humidity: 5% to 95% (non-condensing)
Certifications:
CE
c-UL-us
RoHS

Key Features & Benefits

✅ 4 Analog Output Channels supporting both voltage and current

✅ ±10V and 0–20 mA Output Ranges for flexible signal interfacing

✅ Compact Plug-In Format for easy I/O expansion on Micro800 platforms

✅ 12-bit Resolution for accurate analog signal control

✅ Ideal for Process, Motion, and Temperature Control Systems
