Allen Bradley 5069-L310ER CompactLogix 5380 Controller

The AB 5069-L310ER is a CompactLogix 5380 controller designed for demanding mid-range control applications that require high-speed, high-performance processing with compact form factor efficiency. Equipped with 1MB user memory, dual Ethernet ports with DLR capability, and support for up to 24 EtherNet/IP nodes, this controller offers exceptional scalability and real-time control performance in small to mid-sized systems.

Technical Specifications

Manufacturer: 5069L310ER
Product Series: CompactLogix 5380
Part Number: 5069-L310ER
Controller Type: Programmable Automation Controller (PAC)
User Memory: 1 MB (1024 kBytes)
I/O Capacity: Supports 8 local 5069-series I/O modules
SD Card Support: 1GB (included), expandable to 2GB

Electrical Specifications

Supply Voltage Range: 18–32 VDC (nominal 24 VDC)
Power Consumption: ~5 W (controller only, without I/O modules)
Communication Ports:

• 2 × RJ45 10/100/1000 Mbps Ethernet (w/ DLR & Linear topologies)
• 1 × USB 2.0 non-isolated programming port
  Protocols Supported:
• EtherNet/IP
• TCP/IP
• CIP Motion
• CIP Safety (with safety partner)

Mechanical Specifications

Module Width: 98.1 mm
Module Height: 143.97 mm
Module Depth: 136.81 mm
Mounting Type: DIN rail
Display Type: Integrated character/text display
Form Factor: Compact, single-slot

Environmental Specifications

Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +85°C
Relative Humidity: 5–95% non-condensing
Vibration/Shock Resistance:

• Vibration: 5 g @ 10…500 Hz
• Shock: 30 g
  IP Rating: IP20

Key Features & Benefits

✅ 1 MB high-speed user memory – Optimized for mid-sized machine and process applications

✅ Dual 1Gbps Ethernet ports – Support DLR ring topology, increasing network resilience

✅ Compact, high-performance platform – Supports 24 EtherNet/IP devices and 8 local I/O modules

✅ Enhanced diagnostics and security – Integrated controller diagnostics and role-based access

✅ Supports CIP Motion and CIP Safety (with partner controller) – Ideal for advanced motion and safety integration
