Danfoss 131F8059 Inverter Drive - 11kW, IP20
  1. 131F8059 131B9826 131U7088 131N9837 131N7647 131F8139 131F6623 131F6647 131F0430 131H3659 131L5916 131F6637 131F6641
  2. Danfoss 131F8059 Inverter Drive - 11kW, IP20

Danfoss 131F8059 Inverter Drive – 11kW, IP20

£1,541.94

⚡ Request a Live Quote — we’ll check today’s live pricing and send our best offer.

  • Optimized Motor Control: Provides precise speed and torque control.
  • LonWorks MCA 108 Included: Enables seamless HVAC network connectivity.
  • Compact & Lightweight Design: Ideal for panel-mounted applications.
  • Graphical LCP: Easy-to-use interface for configuration and monitoring.
📦 Fast UK Delivery

In stock now, delivered in 3–5 working days — most orders arrive in 3–4 days. Fully tracked and insured.

🛡️ 24-Month Drive Outlet Warranty
Every product is 100% new, genuine, and backed by our exclusive 2-year warranty. We are an independent supplier and not an authorised distributor. Manufacturer warranties may not apply. See our Terms and Conditions.
Need a Geared Motor to Match This Inverter Drive?

Most inverter drives are installed with a geared motor to achieve the correct speed, torque, and mechanical load control. Visit our sister site, WormGear Motors Online, to find compatible worm gearboxes and IEC electric motors.

Find a Matching Geared Motor
SKU: 131F8059 Category: Tags: , Brand:
Guaranteed Safe Checkout
Extra Features
  • 100% Brand New & Genuine OEM Product
  • Includes Full 2-Year Warranty for Peace of Mind
  • Fast UK & Worldwide Shipping – Fully Tracked
  • Expert Technical Support from Our In-House Engineers
  • Found a Better Price? We’ll Match or Beat It Instantly

Danfoss 131F8059 Inverter Drive – 11kW, IP20

The Danfoss VLT® HVAC Drive FC 102 (131F8059) is designed for precise motor control and energy-efficient operation in HVAC applications. With 11 kW (15 HP) capacity and LonWorks MCA 108 integration, this drive ensures seamless communication, efficiency, and reliability for HVAC systems.

Technical Specifications

Model: 131F8059 (FC-102P11KT4E20H2XGXXXXSXXXXAGBXCXXXXDX)
Type: High-Performance HVAC Variable Frequency Drive (VFD)

Power & Performance

  • Power Rating: 11 kW / 15 HP
  • Phase: Three-phase
  • Mains Voltage: 380 – 480 VAC
  • RFI Filter: H2, RFI Filter

Build & Design

  • Enclosure Type: IP20 / Chassis (E20)
  • Frame Size: B3
  • Coating PCB: Not Coated PCB
  • Local Control Panel (LCP): Graphical LCP

Physical Specifications

  • Gross Weight: 11.45 kg
  • Net Weight: 10.48 kg
  • Volume: 42.336 L
  • Dimensions:
    • Height: 399 mm
    • Width (no C options): 165 mm
    • Width (two C options): 225 mm
    • Depth: 249 mm
    • Depth with Option A/B: 262 mm
  • EAN: 5702427480445

Additional Options & Features

  • Mains Option: No Mains Option
  • Software Release: Latest Standard Software (SXXX)
  • Standard Cable Entries: Included
  • A Option: LonWorks MCA 108 (AG)
  • B Option: No B Option (BX)
  • D Option: No D Option (DX)

Compliance & Standards

  • ECCN EU: X.A.I.003
  • ECCN US: 3A999

Key Features & Benefits:

✅ Optimized Motor Control: Provides precise speed and torque control.

✅ LonWorks MCA 108 Included: Enables seamless HVAC network connectivity.

✅ Compact & Lightweight Design: Ideal for panel-mounted applications.

✅ Graphical LCP: Easy-to-use interface for configuration and monitoring.

📦 Order Today for Fast UK & Europe Delivery!

At Drive Outlet Megastore, we provide the best Danfoss 131F8059 prices, with same-day and next-day shipping available across the UK & Europe.

For more details on the 131F8059 HVAC Drive, or to speak with an expert about the best drive for your application, contact Drive Outlet Megastore.

Our team is ready to help you find the perfect drive solution for your HVAC and industrial automation needs. Get in touch today!

Weight 11.5 kg

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

At Drive Outlet Megastore, we specialize in providing Danfoss drive and automation solutions to businesses across the UK & Europe. With a commitment to same-day and next-day delivery, we ensure you get the parts you need, when you need them. From VLT® and VACON® drives to reliable HVAC and industrial automation components, we offer the most competitive prices on the market, making high-performance Danfoss products more accessible than ever. Shop with us for fast, reliable, and cost-effective Danfoss solutions today!

View all Danfoss products

131F8059-Dimensions.pdfSelection-Guide.pdf
