Omron CJ1W-CLK23 Controller Link Unit

The Omron CLK23 is a Controller Link communication module for CJ-series PLC systems, enabling high-speed, deterministic networking using a 2-wire twisted pair connection. Designed for factory automation systems requiring reliable and synchronized data sharing across multiple nodes, this CPU Bus Unit supports data transmission rates up to 2 Mbps and features a screw connector interface for robust, secure wiring.

The CJ1W-CLK23 is ideal for peer-to-peer communications, data link applications, and distributed control architectures, particularly in systems with multiple PLCs, HMIs, or SCADA nodes requiring cyclic and acyclic data sharing.

Communication Specifications

Model: CJ1WCLK23
Communication Type: Controller Link (deterministic field network)
Transmission Medium: 2-wire twisted pair
Connector Type: Screw terminals
Communication Port(s): 1 × Controller Link port
Data Transmission Speed: 2 Mbps (max)
Topology Support: Bus, ring, or star (with repeater)
Max Number of Nodes: Up to 62 (depending on system design)
Station Address Setting: Via rotary switch

Electrical & Mechanical

• Power Supply: Supplied from CJ-series CPU rack
• Mounting Method: DIN rail via CPU rack
• Unit Type: CPU Bus Unit
• I/O System: CJ I/O Bus
• Product Dimensions (W × H × D): 31 × 90 × 82 mm
• Weight: 110 g (unpacked)

Environmental Ratings

• Operating Temperature: 0 to 55°C
• Storage Temperature: –20 to 75°C
• Humidity Range: 10% to 90% RH (non-condensing)
• Shock Resistance: IEC 60068-2-27 compliant
• Vibration Resistance: IEC 60068-2-6 compliant

System Integration

• Compatible PLC Platforms: CJ1, CJ2, and CJ1M series
• Data Link Support: Cyclic and aperiodic data exchange between PLC nodes
• Usage: Controller-to-controller communication, remote I/O data sharing
• IO-Link Support: Not applicable
• CPU Rack Mount: Yes (counts as one CPU Bus Unit)
• Programming Software: CX-Programmer / CX-Integrator

Applications

Ideal for:

• Factory-wide data link systems
• Distributed motion or process control
• Synchronized control across multiple PLCs
• SCADA-to-PLC and PLC-to-PLC communications
• Industrial automation networks requiring redundancy

Key Features & Benefits

✅ High-Speed Networking: 2 Mbps Controller Link for deterministic real-time data.

✅ Robust Topology Options: Bus, ring, and star layouts supported.

✅ Screw Terminal Wiring: Secure and reliable connection for harsh environments.

✅ CJ-Series Integration: Seamlessly fits into CPU rack with up to 16 CPU Bus Units.

✅ Data Link Ready: Supports both cyclic and acyclic data sharing.

📦 Available from Drive Outlet Megastore

The Omron CJ1W-CLK23 enables efficient and high-speed communication between CJ-series PLCs and peripheral systems across your factory floor. Whether you need to coordinate multi-axis machines or share sensor data system-wide, this module provides the reliable link.
