Omron CP1L-EM30DR-D Compact PLC

The CP1L-EM30DR-D is a powerful compact PLC from Omron’s CP1L series, offering advanced control capabilities with the flexibility of a modular system. Featuring 18 digital inputs, 12 relay outputs, 2 analog inputs, and an integrated Ethernet port, it provides the essential functions for small to mid-size machine automation projects.

With 10K program steps and 32K words of data memory, the unit delivers excellent logic capacity, while supporting analog expansion, encoder inputs, and standard industrial protocols for scalable and connected automation.

Technical Specifications

Model: CP1LEM30DRD
Product Type: Compact PLC with onboard I/O
PLC Series Compatibility: CP1L
Program Capacity: 10K steps
Data Memory Capacity: 32K words
Digital Inputs: 18 (PNP/NPN selectable)
Digital Outputs: 12 (Relay, 2 A)
Analog Inputs: 2 channels (built-in)
Logic Execution Time: 0.55 µs per basic instruction
Max. Local I/O Points: 150
Max. Expansion Units: 3
Encoder Input Channels: 4 (max. 100 kHz)
Pulse Output: Not supported
Function Block Programming: Supported
Real-Time Clock: Integrated
Battery-Free Memory Backup: Yes

Electrical Specifications

• Power Supply Voltage: 24 VDC
• Built-in Auxiliary 24 VDC Output: None
• Input Type: Sink/Source selectable (PNP/NPN)
• Output Type: Relay (2 A per channel)
• Power Consumption: Varies with load and expansion

Communication Interfaces

• Ethernet Port: 1 × Ethernet TCP/IP
• USB Port: Not available
• Serial Ports (Option Boards): RS-232C, RS-422, RS-485 (via option boards)
• Communication Functions: CX-Programmer, FINS, Modbus-RTU (via option), Host Link

CP1L-EM30DR-D Mechanical Specifications

• Mounting Type: DIN-rail
• Dimensions (H × W × D): 90 × 130 × 85 mm
• Weight: 485 g
• Enclosure Type: Compact plastic housing
• Modular Expansion: Up to 3 expansion units

Environmental Conditions

• Operating Temperature: 0 to 55°C
• Storage Temperature: –25 to 70°C
• Operating Humidity: 10% to 90% RH (non-condensing)
• Vibration Resistance: IEC 60068-2-6 compliant
• Shock Resistance: IEC 60068-2-27 compliant
• Protection Rating: IP20 (when mounted in panel)

Key Features & Benefits

✅ Integrated I/O. 18 digital inputs, 12 relay outputs, and 2 analog inputs onboard.

✅ Ethernet Connectivity. Native Ethernet TCP/IP port for networking, remote access, and programming.

✅ Flexible Expansion. Supports up to 3 I/O or analog option units and 150 local I/O points.

✅ Advanced Motion Capabilities. 4 encoder inputs (100 kHz) for position and speed feedback.

✅ Reliable Control Platform. Battery-free memory backup and integrated real-time clock.

📦 Available Now from Drive Outlet Megastore

The Omron CP1L-EM30DR-D is the perfect all-in-one controller for compact machines requiring built-in analog, Ethernet communication, and relay-based output control. Designed for OEMs, system integrators, and panel builders, this model delivers reliability, versatility, and excellent cost efficiency in one sleek unit.

Request a quote or contact our team for expert support and real-time stock availability.

Smart control. Compact design. Built for automation. – Drive Outlet Megastore
