Panasonic GD-10 Double Sheet Detector Sensor Head
The Panasonic GD-10 is a high-precision double sheet detection sensor head, engineered for reliable identification of overlapping sheet materials in printing, packaging, and sheet-feeding systems. With a compact block-style design, the GD-10 offers a 30 mm sensing range and is optimized for inductive detection of metal and conductive sheet layers.
Encased in a robust IP67-rated polyalylate housing, this sensor delivers dependable operation even in harsh industrial environments. The 3-meter pre-wired cable and bracket mounting design ensure quick integration into production lines with minimal setup time.
Technical Specifications
Model: GD-10 Panasonic
Series: GD Series
Sensor Type: Double Sheet Detector (Inductive)
Sensing Range: 30 mm
Detection Principle: High-precision inductive detection
Output Type: Sensor head only – connect to amplifier unit (sold separately)
Terminal Type: Cable (3 m pre-wired)
Mechanical & Material
Body Style: Block
Mounting Style: Bracket mount
Material: Polyalylate (Enclosure)
Dimensions: 12 × 7.1 × 32.2 mm
Weight: Refer to datasheet
Environmental Ratings
IP Rating: IP67
Operating Temperature: -10 to +60 °C
Relative Humidity: 45% to 85% RH (non-condensing)
Certifications: RoHS Compliant
Key Features & Benefits
✅ 30 mm Sensing Range: Accurate detection of double or overlapping metal sheets.
✅ IP67 Enclosure: Durable design for dusty and wet environments.
✅ Compact Block Size: Easily fits into narrow or tight industrial equipment.
✅ Quick Integration: 3 m cable and bracket mount included.
✅ Ideal for Sheet Feeders: Prevents jams and misfeeds in printing or packaging machines.
📦 Order the Panasonic GD-10 from Drive Outlet Megastore
At Drive Outlet Megastore, we offer unbeatable Panasonic GD-10 prices.
Trusted by OEMs and automation integrators worldwide, the GD-10 delivers reliable double sheet detection to maintain productivity and reduce costly downtime. Perfect for high-speed feeders, offset presses, and material handling systems.
Check availability or request a quote today.
Detect doubles. Prevent downtime. — Drive Outlet Megastore
