Pepperl+Fuchs KFU8-UFT-Ex2.D Frequency Converter (231202)

Name: Pepperl+Fuchs KFU8-UFT-Ex2.D Frequency Converter (231202)
SKU: KFU8-UFT-Ex2.D
Price: 747.44 GBP
Availability: InStock

£747.44 inc VAT

In Stock · Delivered in 3–5 Working Days

Estimated UK delivery time, subject to order confirmation, courier services and destination. International delivery times vary.

Technical SpecificationsPepperl+Fuchs

Model	KFU8-UFT-Ex2.D
Input Type	NAMUR or mechanical contacts
Dimensions	40 x 119 x 115 mm (W x H x D)
Connection	Screw terminals
Input Frequency	0.001 … 1000 Hz
Frequency Accuracy	0.5% of measured value
Trip Function	High/low alarm, direction, slip, sync
Open Loop Voltage	Max. 24 V DC
Slip Monitoring Accuracy	1%
Mounting	35 mm DIN rail (EN 60715)

✓ Genuine OEM Parts✓ 2-Year Store-Backed Warranty✓ Technical Support

Found a Better Price? We’ll Match or Beat It InstantlySend us the competing price or quote for a personalised offer.

🛡️ 24-Month Drive Outlet Warranty

Every product is 100% new, genuine, and backed by our exclusive 2-year warranty. We are an independent supplier and not an authorised distributor. Manufacturer warranties may not apply. See our Terms and Conditions.

SKU: KFU8-UFT-Ex2.D Category: Pepperl+Fuchs Modules Tag: KFU8-UFT-Ex2.D Brand: Pepperl+Fuchs

Guaranteed Safe Checkout

Extra Features

100% Brand New & Genuine OEM Product
Includes Full 2-Year Warranty for Peace of Mind
Fast UK & Worldwide Shipping – Fully Tracked
Expert Technical Support from Our In-House Engineers
Found a Better Price? We’ll Match or Beat It Instantly

Pepperl+Fuchs KFU8-UFT-Ex2.D Frequency Converter (231202)

P&F KFU8-UFT-Ex2.D is a versatile 2-channel isolated barrier designed for hazardous area applications requiring frequency monitoring, slip detection, rotation direction evaluation, and synchronization checks. Supporting both NAMUR sensors and dry contacts, this unit offers current output, relay signaling, and passive transistor outputs.

Technical Specifications

Model	KFU8-UFT-Ex2.D
Function	Frequency conversion, slip monitoring, direction and sync indication
Channels	2
Input Frequency	0.001 … 1000 Hz
Input Type	NAMUR or mechanical contacts
Outputs	2 relays, 2 passive transistor outputs, 1 analog current output
Trip Function	High/low alarm, direction, slip, sync
Start-up Override	Programmable
Power Supply	20–90 V DC / 48–253 V AC (50–60 Hz)
Configuration	Front keypad or PACTware

Electrical Features

Relay Outputs	250 V AC / 2 A, 40 V DC / 2 A
Electronic Outputs	40 V DC passive transistor (short-circuit/overload-proof)
Analog Output	0/4 … 20 mA, load ≤ 650 Ω
Fault Signaling	≤ 3.6 mA (downscale), ≥ 21.5 mA (upscale)
Open Loop Voltage	Max. 24 V DC
Accuracy (Analog)	< 30 µA
Slip Monitoring Accuracy	1%
Frequency Accuracy	0.5% of measured value
Input Pulse Width	≥ 250 µs

Environmental Conditions

Operating Temperature	-20 … 60 °C
Protection Class	IP20
Mounting	35 mm DIN rail (EN 60715)
Connection	Screw terminals
Dimensions	40 x 119 x 115 mm (W x H x D)
Weight	Approx. 300 g

Hazardous Area Compliance

Zone Classification	Zone 0, 1, 2 / Div. 1, 2
ATEX Marking	II (1) G [Ex ia Ga] IIC / II (1) D [Ex ia Da] IIIC
IECEx Certification	[Ex ia Ga] IIC / [Ex ia Da] IIIC
Maximum Safe Voltage (Um)	253 V AC / 125 V DC
SIL Rating	SIL 2 (IEC/EN 61508)

Frequently Asked Questions

How can I check whether KFU8-UFT-Ex2.D is the correct replacement?

Check the exact manufacturer part number, electrical ratings, interface type, mounting and equipment compatibility against your existing equipment and the manufacturer’s datasheet.

How quickly can KFU8-UFT-Ex2.D be delivered?

This product is listed as in stock, with estimated UK delivery in 3–5 working days. Delivery depends on order confirmation, courier services and destination.

Where can I check specifications and compatibility?

Review the specification information above and the product’s Downloads or Data Sheets tab, where documents are supplied. Our team can help check part numbers and installation compatibility.

What warranty does Drive Outlet Megastore offer?

Drive Outlet offers its own 2-year return-to-base warranty unless otherwise stated. Manufacturer warranties may not apply; please review the Terms and Conditions before ordering.

Weight	0.3 kg

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Pepperl+Fuchs Supplier UK – Interface Modules, Sensors & Signal Conditioning Parts

Browse Pepperl+Fuchs products for intrinsic safety barriers, interface modules, signal conditioners, sensors, switch amplifiers and industrial control panel spares.

⚙️ Genuine OEM Automation Parts
🔎 Search by Part Number
🚚 Fast UK & International Delivery
🛠️ Technical Sourcing Support

Popular Pepperl+Fuchs Products

Use the product links below as quick routes into this brand. If you already know your part number, use the search bar for the fastest result.

View Pepperl+Fuchs KFD2-GUT-Ex1.D Temperature Converter (231225)
View Pepperl+Fuchs WCS3B-LS311 SSI Read Head (99290-0026)
View Pepperl+Fuchs KFD2-CRG2-Ex1.D Power Supply (255620)
View Pepperl+Fuchs PCV100-F200-B17-V1D-6011-6997 Read Head
View Pepperl+Fuchs KFD0-RO-Ex2 Relay Module (038975)
View Pepperl+Fuchs WCS3B-LS311D SSI Read Head (199290-0027)

Shop Pepperl+Fuchs by Product Category, Series & Specification

Compare Pepperl+Fuchs products by K-System module type, input signal, output function, safety rating, supply voltage, channel count and exact part number.

View Pepperl+Fuchs Modules
View Pepperl+Fuchs Encoders
View Pepperl+Fuchs Power Supplies
View Pepperl+Fuchs Laser Scanners
View Pepperl+Fuchs Relays
View All Pepperl+Fuchs Products

Need Help Finding the Right Pepperl+Fuchs Product?

If you cannot find the exact part number, send us the model code, a photo of the rating plate or the details of the machine it is fitted to. We can help check availability, replacements and suitable alternatives.

Request a Quote / Contact Us

Pepperl+Fuchs FAQs

How do I find the correct Pepperl+Fuchs product?

The fastest way is to search using the exact manufacturer part number or model code. You can also browse this brand page by product category, series and specification to compare close alternatives.

What should I check before buying Pepperl+Fuchs products?

Check the Pepperl+Fuchs model code, channel count, input/output type, hazardous-area approval, supply voltage, switching function and wiring compatibility.

Can you help if my exact Pepperl+Fuchs part number is not listed?

Yes. Send us the part number, a photo of the label or the machine details and we can check availability, replacement options and suitable alternatives.

Are these products suitable for industrial replacement jobs?

These pages are designed for maintenance teams, panel builders, OEM buyers and engineers who need part-number-led industrial automation spares for repairs, upgrades and breakdown support.

How quickly can you supply Pepperl+Fuchs products?

Availability depends on the exact product and quantity required. Check the product page or contact us and we can confirm stock position, lead time and shipping options.

View all Pepperl+Fuchs products

KFU8-UFT-Ex2.D-Datasheet.pdf
