Phoenix Contact 2866750 Power Supply – QUINT-PS/1AC/24DC/5

£235.69 inc VAT

In Stock · Delivered in 3–5 Working Days
Estimated UK delivery time, subject to order confirmation, courier services and destination. International delivery times vary.
Technical SpecificationsPhoenix Contact
Model QUINT-PS/1AC/24DC/ 5
Product Type Switched-mode Power Supply
Series QUINT POWER
Part Number 2866750
Output Current 5 A nominal, 7.5 A POWER BOOST
Parallel and Series Operation Supported
Mounting Type DIN rail, NS 35
Input Type 1-phase AC / DC
Input Frequency 45–65 Hz (AC), 0 Hz (DC)
Enclosure Rating IP20
✓ Genuine OEM Parts✓ 2-Year Store-Backed Warranty✓ Technical Support

Found a Better Price? We’ll Match or Beat It InstantlySend us the competing price or quote for a personalised offer.

🛡️ 24-Month Drive Outlet Warranty

Every product is 100% new, genuine, and backed by our exclusive 2-year warranty. We are an independent supplier and not an authorised distributor. Manufacturer warranties may not apply. See our Terms and Conditions.

SKU: 2866750 Category: Tags: , Brand:
Guaranteed Safe Checkout
Extra Features
  • 100% Brand New & Genuine OEM Product
  • Includes Full 2-Year Warranty for Peace of Mind
  • Fast UK & Worldwide Shipping – Fully Tracked
  • Expert Technical Support from Our In-House Engineers
  • Found a Better Price? We’ll Match or Beat It Instantly

Phoenix Contact 2866750 Power Supply – QUINT-PS/1AC/24DC/5

The Phoenix Contact QUINT-PS/1AC/24DC/5 is a compact primary-switched DIN rail-mounted power supply from the high-performance QUINT POWER series , delivering a reliable 24 V DC output at 5 A . It features advanced Selective Fuse Breaking (SFB) Technology , POWER BOOST for overload startup , and preventive function monitoring to detect critical states before failures occur.

Technical Specifications

Model QUINT-PS/1AC/24DC/ 5
Part Number 2866750
Product Type Switched-mode Power Supply
Series QUINT POWER
Input Frequency 45–65 Hz (AC), 0 Hz (DC)
Output Voltage 24 V DC ±1% (adjustable 18–29.5 V DC)
Output Current 5 A nominal, 7.5 A POWER BOOST
Selective Fuse Breaking (SFB) 30 A for 12 ms
Efficiency > 90% at 230 V AC
Ripple Voltage < 40 mVPP
Power Loss 15 W max at full load
Enclosure Rating IP20
Mounting Type DIN rail, NS 35
Connection Method Pluggable screw terminal
Dimensions (W × H × D) 40 × 130 × 125 mm
Weight Approx. 0.9 kg
Input Voltage Range AC: 85–264 V AC DC: 110–350 V DC Input Frequency: 45–65 Hz (AC), 0 Hz (DC) Output Voltage: 24 V DC ±1% (adjustable 18–29.5 V DC) Output Current: 5 A nominal, 7.5 A POWER BOOST Selective Fuse Breaking (SFB): 30 A for 12 ms Efficiency: > 90% at 230 V AC Ripple Voltage: < 40 mVPP Power Loss: 15 W max at full load Enclosure Rating: IP20 Mounting Type: DIN rail, NS 35 Connection Method: Pluggable screw terminal Dimensions (W × H × D): 40 × 130 × 125 mm Weight: Approx. 0.9 kg

Input Characteristics

Input Type 1-phase AC / DC
Nominal Input Range 100–240 V AC
Extended Range 85–264 V AC / 110–350 V DC
Power Consumption 145 VA
Inrush Current < 15 A
Internal Fuse 5 A slow-blow
Power Factor 0.94
Transient Protection Varistor
Buffering Time > 55 ms at 120/230 V AC
Recommended Protection 6–16 A breaker (B, C, D, K)

Output & Monitoring Features

Output Characteristic U/I (Voltage/Current)
Output Power 120 W
POWER BOOST 7.5 A for heavy load startup
Parallel and Series Operation Supported
Short-Circuit Protection Yes
DC OK Signal (Active) High signal if UOUT > 0.9 × UN Max: 24 V DC, 20 mA
DC OK Relay (Floating) Contact closes above threshold Max: 30 V AC / 24 V DC, 1 A
POWER BOOST Signal Yellow LED and active signal output Max: 24 V DC, 20 mA

Mechanical & Environmental

Housing Material Galvanized steel and aluminum
Mounting Position Horizontal on DIN rail
Cooling Convection (fanless)
Ambient Temp (Operating) –25°C to +70°C (derating >60°C)
Storage Temp –40°C to +85°C
Max Altitude 5000 m
Vibration 2.3 g (15–150 Hz, 90 min)
Shock 30 g / 18 ms (IEC 60068-2-27)
Humidity ≤ 95% (non-condensing)
Protection Class I
Pollution Degree 2
MTBF (IEC 61709) 1,134,000 h @ 25°C 635,000 h @ 40°C 270,000 h @ 60°C

Related Products & Helpful Links

Frequently Asked Questions

How can I check whether 2866750 is the correct replacement?

Check the exact manufacturer part number, electrical ratings, interface type, mounting and equipment compatibility against your existing equipment and the manufacturer’s datasheet.

How quickly can 2866750 be delivered?

This product is listed as in stock, with estimated UK delivery in 3–5 working days. Delivery depends on order confirmation, courier services and destination.

Where can I check specifications and compatibility?

Review the specification information above and the product’s Downloads or Data Sheets tab, where documents are supplied. Our team can help check part numbers and installation compatibility.

What warranty does Drive Outlet Megastore offer?

Drive Outlet offers its own 2-year return-to-base warranty unless otherwise stated. Manufacturer warranties may not apply; please review the Terms and Conditions before ordering.

Weight 0.9 kg
