Schneider BMXCPS4022 Redundant Power Supply Module

The Schneider BMXCPS4022 is a high-performance Modicon X80 redundant power supply module, designed to provide reliable power to Modicon M580 and M340 programmable automation controllers (PACs). It operates with a 24–48V DC input and delivers a 40W output, ensuring stable and efficient power conversion for industrial automation systems.

This module features an IP20-rated chassis, making it suitable for panel-mounted installations in control cabinets. It is engineered for demanding applications, offering robust performance and seamless integration with Schneider Electric’s Modicon X80 I/O platform.

Technical Specifications

Model: BMXCPS4022
Type: Redundant Power Supply Module for Modicon X80

BMXCPS4022 Performance & Capacity

• Primary Voltage:
  • 24V to 48V DC
• Primary Voltage Limits:
  • 18V to 62.4V
• Supply Circuit Type:
  • DC
• Secondary Power Output:
  • 18W at 3.3V DC (I/O Module Logic Power Supply)
  • 40W at 24V DC (I/O Module & Processor Power Supply if 3.3V Not Loaded)
• Current at Secondary Voltage:
  • 5.5A at 3.3V DC (I/O Module Logic Power Supply)
  • 1.67A at 24V DC (I/O Module & Processor Power Supply)
• Input Current:
  • 1.9A at 24V
  • 1A at 48V
• Inrush Current:
  • 60A at 24V
  • 60A at 48V
• Maximum Power Dissipation:
  • 8.5W
• Protection Types:
  • Internal Fuse (Not Accessible) – Primary Circuit
  • Overload Protection – Secondary Circuit
  • Overvoltage Protection – Secondary Circuit
  • Short-Circuit Protection – Secondary Circuit
• Advanced Diagnostics Available via Network:
  • Redundancy Information
  • Redundancy Test
  • Temperature Sensing
  • Remaining Lifetime
  • Uptime Duration
• Insulation Resistance:
  • ≥ 100 MΩ (Primary/Ground & Primary/Secondary)
• Dielectric Strength:
  • 1500V Primary/Ground
  • 1500V Primary/Secondary
• Immunity to Microbreaks:
  • 1 ms

Connectivity & Controls

• Electrical Connections:
  • 2-Pin Connector – Alarm Relay
  • 5-Pin Connector – Line Supply, Protective Earth
• Control Type:
  • RESET Push-Button (Cold Restart)
• Local Signaling:
  • 1 LED (Green) – Presence of Voltages (OK)
  • 1 LED (Green) – Redundancy OK
  • 1 LED (Green) – Power Supply Status
• Maximum Cable Distance Between Devices:
  • 10m
  • 15m

Power & Environmental Specifications

• MTBF Reliability: 752,000 Hours
• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 10% to 95% (Non-Condensing)
• Operating Altitude:
  • 0 to 2000 m (Standard Operation)
• IP Degree of Protection: IP20

BMXCPS4022 Physical Specifications

• Net Weight: 0.81 kg
• Package 1 Dimensions (H x W x L): 18.00 cm x 25.00 cm x 9.00 cm
• Package 1 Weight: 660 g
• Package 2 Dimensions (H x W x L): 30.00 cm x 30.00 cm x 40.00 cm
• Package 2 Weight: 4.40 kg
• Package 3 Dimensions (H x W x L): 60.00 cm x 80.00 cm x 70.00 cm
• Package 3 Weight: 43.20 kg
• Number of Units in Package 1: 1
• Number of Units in Package 2: 6
• Number of Units in Package 3: 48

Key Features & Benefits:

✅ DC Voltage Compatibility: Operates on 24-48V DC input.

✅ Reliable Power Output: Provides stable 24V DC and 3.3V DC power for I/O modules and processors.

✅ Integrated Protection Features: Overload, overvoltage, and short-circuit protection.

✅ Cold Restart Function: RESET push-button for quick system recovery.

✅ Redundancy Monitoring & Diagnostics: Ensures high availability and reliable operation.

✅ Compact & Modular: Fits seamlessly into Modicon X80 racks.

✅ Industrial-Grade Performance: Designed for high-reliability and long-term operation.
