Siemens 6ES7332-5HD01-0AB0 | SIMATIC S7-300 SM 332 Analog Output Module

6ES73325HD010AB0 Siemens S7-300 SM 332 Analog Output Module – 4 AO Isolated, Voltage/Current, 11/12 Bit Resolution

Technical Specifications

Model: 6ES7332-5HD01-0AB0 Siemens
Type: Analog Output Module, Isolated
Channels: 4 Analog Outputs (AO) – Voltage / Current (U/I)
Resolution: 11 / 12 bits
Connection: 20-pole front connector (sold separately)
Hot Swappable: Removing and inserting possible with active backplane bus
Diagnostics: Built-in module diagnostics for reliable operation

Performance & Features

• Isolated Analog Outputs: Ensures signal integrity and system protection
• Versatile Output Signals: Supports both voltage and current outputs
• High-Resolution Outputs: 11 / 12-bit resolution for precise analog control
• Integrated Diagnostics: Continuous system monitoring and fault detection
• Hot Swap Capability: Maintain system operation during module replacement
• Phase-Out Notice: Product phase-out effective 01.10.2023

Physical Specifications

• Net Weight: 0.252 kg
• Packaging Dimensions (W x H x D): 12.80 cm x 15.00 cm x 5.00 cm
• Package Size Unit of Measure: CM
• Quantity Unit: 1 Piece
• Packaging Quantity: 1
• Country of Origin: Germany

Product Lifecycle & Compliance

• Product Lifecycle (PLM): PM400 – Product Phase-Out (Since 01.10.2023)
• Export Control Regulations: AL: N / ECCN: 9N9999
• RoHS Compliance: Since 31.03.2008
• WEEE Take-Back Obligation: Yes
• REACH Compliance: Compliant
• SCIP Number: b75818ad-51e8-4bc2-b88a-ee5fcb4be5c9

Additional Product Information

• EAN: 4025515061298
• UPC: 040892562316
• Commodity Code: 85389091
• Catalog ID: ST73
• Product Group: 2288
• Group Code: R151
• Product Class: A – Standard stock item, returnable within guidelines

Reliable Analog Output Module for Industrial Applications

The Siemens 6ES7332-5HD01-0AB0 SM 332 Analog Output Module provides high-accuracy isolated analog outputs, supporting voltage and current signals. Designed for SIMATIC S7-300 systems, it offers robust diagnostics and hot-swapping for maximum system uptime.

Key Features & Benefits:

✅ 4 Isolated Analog Outputs (Voltage/Current)

✅ 11 / 12-Bit High-Resolution Outputs

✅ Integrated Diagnostics for Enhanced Reliability

✅ Hot-Swappable with Active Backplane Bus

✅ Suitable for Critical Process Control Applications
