Siemens 6SL3244-0BB12-1FA0 SINAMICS G120 CU240E-2 PN E-Type

The Siemens 6SL3-244-0BB12-1FA0 CU240E-2 PN E-Type control unit offers high-performance drive control with PROFINET connectivity and integrated safety (STO). With multiple I/O options and user-friendly interfaces, it supports versatile industrial automation and safety applications.

Technical Specifications

• Model: 6SL3244-0BB12-1FA0 Siemens
• Series: SINAMICS G120
• Control Unit Type: CU240E-2 PN E-Type
• Communication: PROFINET
• Integrated Safety Function: STO (Safe Torque Off)
• Inputs/Outputs:
  • 6 Digital Inputs
  • 3 Digital Outputs
  • 2 Analog Inputs
  • 2 Analog Outputs
  • 1 Functional DI (for PTC/KTY sensor)
• Interfaces:
  • USB
  • SD/MMC card slot
• Protection Rating: IP20
• Ambient Temperature: 0 to +50 °C
• Mounting: DIN rail in SINAMICS G120 drive system
• Lifecycle Status: Active

Function & Application

Purpose:
Enables advanced motor control and drive communication via PROFINET, featuring integrated safety (STO) for secure, flexible industrial automation with SINAMICS G120 drives.

Typical Applications:

• Industrial automation with PROFINET-based control
• Safety-critical motor applications (STO compliant)
• Pumping, ventilating, and conveying systems
• Applications requiring precise analog/digital I/O

Recommended Accessories

• 6SL3210-1PE14-3UL1 – PM240-2 Power Module, 1.1 kW HO / 1.5 kW LO, Integrated Braking Chopper

Delivery & Compliance

• Packaging Dimensions: 93.00 × 240.00 × 68.00 mm
• Net Weight: 0.490 kg
• Packaging Quantity: 1 Piece
• Country of Origin: Great Britain
• Estimated Dispatch Time: 3 Working Days

Product Compliance & Classification

• RoHS Compliance: Since 01.07.2006
• WEEE Take-Back Obligation: Yes
• SCIP Number: 0b37f6ab-4349-4181-8c3b-1aac3ae004b9
• REACH Substances:
  • Lead (CAS 7439-92-1) > 0.1%
  • Lead monoxide (CAS 1317-36-8) > 0.1%
  • Silicic acid, lead salt (CAS 11120-22-2) > 0.1%
  • 6,6′-di-tert-butyl-2,2′-methylenedi-p-cresol > 0.1%
  • Bisphenol A (CAS 80-05-7) > 0.1%
• Commodity Code: 85049090
• Catalog ID: D11.1SD
• Product Group: 9779
• Group Code: R220
• Product Class: A – Stock item, returnable
• EAN: 4042948661864
• UPC: 040892941999

Key Features & Benefits:

✅ STO Safety Functionality: Enables Safe Torque Off for enhanced operator and system protection.

✅ 6 DI, 3 DO, 2 AI, 2 AO: Flexible I/O for sensor integration and analog control.

✅ PROFINET Network Ready: Supports fast and reliable industrial Ethernet communication.

✅ Sensor Integration: Supports PTC/KTY motor temperature sensors.

✅ USB & SD/MMC Interface: Simplified diagnostics, updates, and commissioning.
