Allen Bradley 1762-OA8 MicroLogix 1200 Digital Output Module – 8-Point, 120/240V AC Triac Outputs

The Allen Bradley 1762-OA8 is an 8-point AC digital output module designed for use with the MicroLogix 1200 PLC platform. This high-quality output module enables switching of AC loads such as contactors, relays, indicator lamps, and solenoids with a reliable triac-based design for long service life and consistent performance.

Operating at 120 to 240V AC, the 1762-OA8 provides dependable control for medium-duty AC devices while maintaining the compact and modular profile of the MicroLogix 1200 system. With screw terminal connections and easy DIN rail mounting, it’s ideal for control panels requiring simple expansion of AC outputs.

Technical Specifications

Model: 1762-OA8 Allen Bradley
Series: MicroLogix 1200 Expansion I/O
Product Type: Digital Output Module
Number of Digital Outputs: 8
Number of Digital Inputs: 0
Output Type: Triac (AC switching)
Output Voltage Range: 120…240V AC
Output Current per Point: 0.25A
Output Signal Type: AC
Field Connection: Screw terminals
Short-Circuit Protection: No (external fusing recommended)

Electrical & Performance Details

• Outputs: 8 AC triac outputs for resistive and inductive loads
• Voltage Range: 120 to 240V AC
• Current Rating: 0.25A per channel
• Switching Device: Solid-state triac for reliable, contactless operation
• Recommended Protection: External fuse or circuit breaker per output group
• System Interface: Directly connects to MicroLogix 1200 base controller

Mechanical Specifications

• Height: 90 mm
• Width: 40.4 mm
• Depth: 87 mm
• Mounting: DIN Rail (35 mm top hat)
• Connection Type: Screw terminal connections

Environmental & Application Suitability

• Typical Applications: HVAC control panels, motor starters, lighting control, solenoid actuation, and small automation systems
• Use Case: Expanding MicroLogix 1200 PLCs with additional AC outputs
• Installation Environment: Clean industrial enclosures with proper air circulation

Compliance & Certifications

• CE Marked: Yes
• UL / cUL Listed: Yes
• RoHS Compliant: Yes

Key Features & Benefits

✅ 8 AC triac outputs for robust control of resistive and inductive loads.

✅ 120/240V AC operation compatible with a wide range of industrial devices.

✅ Reliable solid-state switching with long service life and low maintenance.

✅ Screw terminal connections ensure secure and simple field wiring.

✅ Compact DIN rail design integrates easily into MicroLogix 1200 systems.
