SICK KTM-LP22182P Contrast Sensor – Laser, 50 mm Range (1109747)

The SICK KTM-LP22182P is a compact, high-performance contrast sensor engineered for fast and precise detection of marks and contrasts on packaging, films, and labels. Equipped with a red laser light source and teach-in functionality, it offers ultra-fast switching at 4 kHz, making it ideal for web speeds up to 10 m/s.

Housed in a small 12 mm-wide body, this sensor delivers accuracy down to 0.08 mm and features a round 1.7 mm light spot optimized for pinpoint mark recognition — even in high-speed applications.

Technical Specifications

Model: KTM-LP22182P SICK
Part Number: 1109747
Product Type: Laser contrast sensor with teach-in
Sensing Distance: ≤ 50 mm
Sensing Distance Tolerance: ±30 mm
Light Source: Red laser (Class 1)
Wavelength: 680 nm
Light Spot Size: Ø 1.7 mm (at 50 mm)
Light Spot Direction: Round
Adjustment Method: 2-point static/dynamic teach-in + proximity to mark (ET mode)
Max. Web Speed: 10 m/s
Switching Frequency: 4,000 Hz
Response Time: 125 µs
Jitter: 57 µs
Accuracy: 0.08 mm
Output Type: PNP
Switching Mode: Light/dark switching
Output Current Max.: 100 mA
Input Function: Dynamic teach-in (ET)
Retention Time (ET): 250 ms
Circuit Protection: Reverse polarity, UV protection, short-circuit protected
Enclosure Rating: IP67
Protection Class: III

Mechanical Data

Dimensions (W × H × D): 12 mm × 31.5 mm × 21 mm
Housing Design: Ultra-compact rectangular
Housing Material: ABS plastic
Front Optics: PMMA
Weight: Approx. 24 g
Connection: 4-pin M12 male connector, 0.3 m cable
Indicators:

• Green LED (Power ON)
• Yellow LED (Output Q status)

Applications

Ideal For:

• Mark detection on high-speed labeling and printing machines
• Color contrast sensing in packaging lines
• Web edge control in textile and film production
• Position detection in bottling and food packaging

Key Features & Benefits

✅ Laser Precision: Class 1 red laser with 0.08 mm accuracy.

✅ Ultra-Fast Detection: 125 µs response time and 4 kHz switching frequency.

✅ Simple Teach-In: Supports static, dynamic, and proximity-based mark learning.

✅ Compact Format: Only 12 mm wide — fits into tight machinery slots.

✅ High IP Rating: IP67 enclosure for industrial environments.
