SICK SKM36-HFA0-K02 Motor Feedback System (1034094)

The SICK SKM36-HFA0-K02 is a high-performance motor feedback system designed for precise rotary position detection in servo drive applications. Equipped with a tapered shaft and spring-mounted stator coupling, this compact encoder delivers accurate feedback even in dynamic and demanding environments. With a robust mechanical design and high-resolution sine/cosine interface, it ensures reliable performance in automation, robotics, and motion control systems.

Note: M3 mounting screws for stator coupling are not included with delivery. Please use part number 1131701 for a packaging unit of 40 pcs.

Technical Specifications

Model: SKM36-HFA0-K02 SICK
Part Number: 1034094
Product Type: Motor feedback system for servomotors
Interface: Sine/Cosine
Output Frequency: ≤ 65 kHz
Supply Voltage: 7 V DC to 12 V DC (Recommended: 8 V DC)
Current Consumption: 60 mA
MTTFD: 210 years (EN ISO 13849)
Connection Type: Male connector, 8-pin, radial

Mechanical Data

Shaft Version: Tapered shaft
Mounting Interface: Spring mounting plate, stator coupling
Flange Type: Stator coupling
Weight: ≤ 0.07 kg
Moment of Inertia (Rotor): 4.5 gcm²
Operating Speed: 9,000 RPM (min⁻¹)
Angular Acceleration: ≤ 500,000 rad/s²
Operating Torque: 0.2 Ncm
Startup Torque: +0.3 Ncm
Permissible Static Movement: ±0.1 mm radial, –0.4 mm axial, +0.2 mm axial
Permissible Dynamic Movement: ±0.05 mm radial, ±0.1 mm axial
Bearing Life Expectancy: 3.6 x 10⁹ revolutions
Dimensions: See technical drawings

Applications

Ideal For:

• Precision feedback in servo drive systems
• Robotics and machine tools
• Packaging and printing machinery
• Industrial automation with tight space constraints

Key Features & Benefits

✅ High Durability: Rated MTTFD of 210 years with robust mechanical design.

✅ Compact Format: Lightweight and slim for tight machine integration.

✅ High-Speed Capable: Operates up to 9,000 RPM with low inertia.

✅ Versatile Mounting: Spring-mounted stator coupling for axial and radial tolerance.

✅ Accurate Output: High-frequency sine/cosine signals up to 65 kHz.
