SICK UM30-211111 Ultrasonic Distance Sensor (6037660)

The SICK UM30-211111 is a high-precision ultrasonic distance sensor built for close-range object detection in industrial environments. With a robust cylindrical M30 design and advanced signal filtering, it reliably measures distances from 30 mm to 250 mm (up to 350 mm limit) — even on challenging materials like transparent films, curved surfaces, or reflective objects.

Technical Specifications

Model: UM30-211111
Part No.: 6037660
Product Type: Ultrasonic Distance Sensor
Target Type: Natural objects (non-cooperative targets)
Technology: Ultrasonic, straight-beam detection
Sensor Family: UM30

Detection Performance

Operating Range: 30 mm to 250 mm
Limiting Range: Up to 350 mm
Resolution: ≥ 0.18 mm
Repeatability: ± 0.15%
Measurement Accuracy: ± 1%
Temperature Compensation: Integrated
Ultrasonic Frequency (Typical): 320 kHz

Response Time: 32 ms
Switching Frequency: 25 Hz
Output Time: 8 ms

Detection Features:

• Adjustable switching point and window
• Background suppression (ObSB)
• Foreground suppression
• Multiplexing for up to 50 sensors
• Teach-in and reset functions
• Configurable filters and beam sensitivity

Electrical Interface

Supply Voltage (UB): 9 V DC to 30 V DC
Power Consumption: ≤ 2.4 W
Initialization Time: < 300 ms
Indication: LED display + 2 status LEDs
Protection Class: III
Enclosure Rating: IP65 / IP67

Mechanical Data

Design: Cylindrical
Dimensions (W × H × D): 30 mm × 30 mm × 84 mm
Thread Size: M30 × 1.5
Connection Type: M12, 5-pin male connector
Housing Material:

• Body: Nickel-plated brass
• Cap: PBT
• Transducer: Polyurethane foam & glass epoxy
  Weight: Approx. 150 g

Safety & Compliance

• MTTFd: 101 years
• DCavg: 0%
• CE Certified
• cULus Listed
• RoHS Compliant

Applications

Ideal For:

• Liquid level monitoring in tanks
• Object presence detection on conveyors
• Roll diameter monitoring
• Fill height control for containers and packaging
• Short-range precise measurement with ultrasonic immunity to dust or mist

Key Features & Benefits

✅ Reliable Short-Range Measurement: Measures from 30 mm to 250 mm, even on non-reflective or transparent surfaces.

✅ Compact Cylindrical Build: M30 threaded metal housing simplifies mounting in tight spaces.

✅ Advanced Signal Processing: Filters, synchronization, and multiplexing eliminate cross-talk between sensors.

✅ Flexible Integration: IO-ready interface with LED indicators and teach-in for on-site setup.

✅ IP67 Protection: Rugged enclosure withstands industrial washdowns, dust, and moisture.
