SICK UM30-213113 Ultrasonic Distance Sensor (6036918)

£563.43 inc VAT

In Stock · Delivered in 5–7 Working Days
Estimated UK delivery time, subject to order confirmation, courier services and destination. International delivery times vary.
Technical SpecificationsSICK
Model UM30-213113
Product Type Ultrasonic distance sensor
Supply Voltage 9 V DC to 30 V DC
Operating Range 200 mm to 1,300 mm
Limiting Range Up to 2,000 mm
SICK Part Number SICK 6036918
Resolution ≥ 0.18 mm
Output Type Analog (auto-selecting voltage/current)
Connection Type M12 male connector, 5-pin
Ultrasonic Frequency 200 kHz
✓ Genuine OEM Parts✓ 2-Year Store-Backed Warranty✓ Technical Support

Found a Better Price? We’ll Match or Beat It InstantlySend us the competing price or quote for a personalised offer.

24-Month Drive Outlet Warranty

Every product is 100% new, genuine, and backed by our exclusive 2-year warranty. We are an independent supplier and not an authorised distributor. Manufacturer warranties may not apply. See our Terms and Conditions.

Extra Features
  • 100% Brand New & Genuine OEM Product
  • Includes Full 2-Year Warranty for Peace of Mind
  • Fast UK & Worldwide Shipping – Fully Tracked
  • Expert Technical Support from Our In-House Engineers
  • Found a Better Price? We’ll Match or Beat It Instantly

SICK UM30-213113 Ultrasonic Distance Sensor (6036918)

The SICK UM30-213113 is a high-precision ultrasonic distance sensor engineered for longer-range detection of natural objects. With an operating range up to 1.3 meters and advanced analog output flexibility, it supports accurate, non-contact measurement in a wide array of industrial applications.

Technical Specifications

Model UM30-213113
SICK Part Number SICK 6036918
Product Type Ultrasonic distance sensor
Application Medium- to long-range non-contact measurement
Operating Range 200 mm to 1,300 mm
Limiting Range Up to 2,000 mm
Target Material Natural objects (diffuse reflectors)
Resolution ≥ 0.18 mm
Repeatability ± 0.15%
Measurement Accuracy ± 1%
Ultrasonic Frequency 200 kHz
Temperature Compensation Yes
Response Time 92 ms
Output Time 23 ms
Functional Features Teach-in and scaling of analog output Invertible analog output Automatic voltage/current analog output selection Synchronization (up to 50 sensors, no cross talk) Adjustable filters: value, strength, suppression, area, sound beam LED display with optional deactivation Factory reset function

Electrical Interface

Supply Voltage 9 V DC to 30 V DC
Power Consumption ≤ 2.4 W
Initialization Time < 300 ms
Output Type Analog (auto-selecting voltage/current)
Display & Indication LED display + 2 status LEDs
Protection Class III
Connection Type M12 male connector, 5-pin

Mechanical Data

Enclosure Rating IP65 / IP67
Housing Design Cylindrical with straight-sensing axis
Dimensions (W x H x D) 30 mm x 30 mm x 84 mm
Thread Size M30 × 1.5
Weight 150 g
Housing Material Body: Nickel-plated brass and PBT Transducer: Polyurethane foam & glass epoxy resin Weight: 150 g

Safety-Related Data

MTTFD (Mean Time to Dangerous Failure) 101 years
DCavg 0%

Ambient Conditions

Operating Temperature Not specified (typically –25 °C to +70 °C for UM30 series)
Storage Temperature Not specified

Certificates and Compliance

European Conformity (CE)
IP65 / IP67 rated for industrial environments
RoHS-compliant construction (on request)

Related Products & Helpful Links

Frequently Asked Questions

How can I check whether UM30-213113 is the correct replacement?

Check the operating voltage, sensing or protective range, output type, connections and required accessories against your existing installation or the relevant manufacturer datasheet.

How quickly can UM30-213113 be delivered?

This product is listed as in stock, with estimated UK delivery in 3–5 working days. Delivery depends on order confirmation, courier services and destination.

Where can I check specifications and compatibility?

Review the specification information above and the product’s Downloads or Data Sheets tab, where documents are supplied. Our team can help check part numbers and installation compatibility.

What warranty does Drive Outlet Megastore offer?

Drive Outlet offers its own 2-year return-to-base warranty unless otherwise stated. Manufacturer warranties may not apply; please review the Terms and Conditions before ordering.

Weight 0.15 kg
